Power Computers
4
© Moxa Inc. All rights reserved. Updated May. 20, 2015. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
All expansion modules can be used on any of Moxa’s embedded computers that come with the peripheral expansion slots. Refer to the following chart.
Model Name
Serial Ports Isolation Switch LAN Connector Type PCI
RS-
232/422/485
RS-
232/485
2 kV
Digital
10/100
Mbps
10/100 Mbps
(RJ45)
Fiber 100
Mbps (ST)
DB9 RJ45
Terminal
Block
ST 3.3/5 V
DA-SP08-I-DB
8 –
P
– – –
P
– – – –
DA-SP08-DB
8 – – – – –
P
– – – –
DA-SP08-I-TB
8 –
P
– – – – –
P
– –
DA-SP38-I-TB
– 8
P
– – – – –
P
– –
DA-SW08-RJ
– – – 8 – – –
P
– – –
DA-LN04-RJ
– – – – 4 – –
P
– – –
DA-UPCI-DK
– – – – – – – – – –
P
DA-FX04-MM-ST-T
– – – – –
P
– – –
P
–
DA-IRIGB-4DIO-PCI104-EMC4
– – – – – –
P
– – – –
DA-SP08-I-EMC4-DB
8 –
P
– – –
P
– – – –
DA-SP08-I-EMC4-TB
8 –
P
– – – – –
P
– –
Module Models DA-682A DA-710 DA-683
DA-SP08-DB 8-port Serial Module (RS-232/422/485)
P P P
DA-SP08-I-DB 8-port Serial Module (RS-232/422/485)
P P P
DA-SP08-I-TB 8-port Serial Module (RS-232/422/485)
P P P
DA-SP38-I-TB 8-port Serial Module (RS-422/485)
P
P P
DA-LN04-RJ 4-port LAN Module (10/100 Mbps)
P P P
DA-SW08-RJ 8-port Switch Module (10/100 Mbps)
P P P
DA-UPCI-DK PCI Module
P P P
DA-FX04-MM-ST-T 4-port Fiber LAN Module (100 Mbps)
P P P
DA-IRIGB-4DIO-PCI104-EMC4 Time Synchronization Module
P P P
DA-SP08-I-EMC4-DB 8-port Serial Module (RS-232/422/485)
P P P
DA-SP08-I-EMC4-TB 8-port Serial Module (RS-232/422/485)
P P P
DA-FX04-MM-ST-T Hardware Specifications
Ordering Information
Compatibility Chart for Peripheral Expansion Modules and Embedded Computers
Available Models
DA-IRIGB-4DIO-PCI104-EMC4: 1 IRIG-B signal input port, 3 digital inputs, 4 digital outputs
DA-SP08-I-DB: 8-port RS-232/422/485 serial module with DB9 connector and digital isolation
DA-SP08-DB: 8-port RS-232/422/485 serial module with DB9 connector
DA-SP08-I-TB: 8-port RS-232/422/485 serial module with terminal block connector and digital isolation
DA-SP38-I-TB: 8-port RS-422/485 serial module with terminal block connector and digital isolation
DA-SW08-RJ: 8-port 10/100 Mbps unmanaged switch module
DA-LN04-RJ: 4-port 10/100 Mbps LAN module
DA-UPCI-DK: Universal PCI development kit
DA-FX04-MM-ST-T: 4-port (100BaseFX) ber LAN module with multi-mode, ST connector, supports IP Teaming
DA-SP08-I-EMC4-DB: 8-port RS-232/422/485 serial module with DB9 connector, digital isolation, and capable of withstanding EMS Level 4
environments
DA-SP08-I-EMC4-TB: 8-port RS-232/422/485 serial module with terminal block connector, digital isolation, and capable of withstanding EMS Level 4
environments
Fiber Interface
Number of Ports: 4 (100BaseFX)
Fiber Mode: Multi-mode
Connector Type: ST
Optical Wavelength: 0 to 2 km, 1310 nm (62.5/125 μm, 500 MHz*km)
Min-TX Output: -20 dBm
Max-TX Output: -14 dBm
RX Sensitivity: -34 dBm
Physical Characteristics
Weight: 495 g
Dimensions: 132 x 150 x 42 mm (5.20 x 5.91 x 1.65 in)
Environmental Limits
Operating Temperature: -40 to 70°C (-40 to 158°F)
Standards and Certifications
EMC: EMC Level 4, ESD Level 4, criteria A
Software Functions
IEEE 1588 or IP Teaming Selectable (Default =IP Teaming): Supports
4 modes
AFT: Adaptor Failover Teaming
SFT: Switch Fault Tolerance
ALB: Adaptor Failover and Load Balancing
Link Aggregation: supported
