DA-681 Linux Introduction
1-3
ATTENTION
Refer to
http://www.debian.org/ and http://www.gnu.org/ for information and documentation of the
Debian
GNU/Linux and free software concept.
ATTENTION
The a
bove software architecture is only an example. Different models or different build revisions of the
Linux
operating system may include components
not shown in the above graphic.
Read-only Root File System
The pre-installed root file system is protected in a read-only partition to prevent file system crash problems
normally caused by power loss. But some directories or files, such as /home,
/root, /var, /etc/network/, /etc/ppp/, /ect/openvpn/, and /etc/resolv.conf, which need write
permission, are located in another writable partition and formatted with the EXT2 file system. You can
read/write above files or directories directly without re-mounting it.
Software Components
The DA-681-LX pre-installed Debian Etch 4.0r2 Linux distribution has the following software components:
Component Version Description
acpid 1.0.4-5 Utilities for using ACPI power management
adduser 3.102 Add and remove users and groups
apache2 2.2.3-4+etch6 Next generation, scalable, extendable web server
apache2-mpm-prefork 2.2.3-4+etch6 Traditional model for Apache HTTPD 2.1
apache2-utils 2.2.3-4+etch6 Utility programs for webservers
apache2.2-common 2.2.3-4+etch6 Next generation, scalable, extendable web server
apt 0.6.46.4-0.1 Advanced front-end for dpkg
apt-utils 0.6.46.4-0.1 APT utility programs
aptitude 0.4.4-4 Terminal-based apt frontend
base-files 4 Debian base system miscellaneous files
base-passwd 3.5.11 Debian base system master password and group
bash 3.1dfsg-8 The GNU Bourne Again SHell
binutils 2.17-3 The GNU assembler, linker and binary utilities
bridge-utils 1.2-1 Utilities for configuring the Linux ethernet bridge
RS-232/422/485, Ethernet, PCMCIA, CompactFlash, SATA, USB
Memory Control, Schedule, Process
PCMCIA, CF, WLAN, USB, UART, RTC, VGA
TCP, IP, UDP, CMP, ARP, HTTP, SNMP, SMTP
Daemon (Apache, Telnet, FTPD)
Application Interface (POSIX, Socket, Secure Socket)
User Applications
File
System
Hardware
Micro Kernel
Device Driver
Protocol Stack
API
AP
Linux
Kernel
