Moxa DA-681-I-DP-LX Технические характеристики онлайн
1
www.moxa.com
info@moxa.com
Power Computers
DA-681 Series
x86 rackmount embedded computers with 4 isolated RS-232 and
8 isolated RS-485 ports, 6 LANs, VGA, CompactFlash, USB
The DA-681 computer is based on the Intel x86 processor and
supports VGA, 6 Ethernet ports, 4 RS-232 and 8 RS-485 serial ports
with isolation, CompactFlash, and USB. The DA-681 comes in a
standard 19-inch, 1U high form factor, making it an ideal platform for
industrial applications.
With its robust design, the DA-681 is suitable for industrial automation
applications that require standard 19-inch rackmount solutions,
such as power automation, transportation, and oil and gas. Another
plus is that the serial ports come with 2 kV digital galvanic isolation
protection to guarantee communication reliability in harsh industrial
environments. In addition, the DPP-T models are compliant with
the IEC 61850-3 standard, making them ideal for power substation
automation systems.
The DA-681 runs Linux or Windows Embedded Standard 2009
(pre-installed), providing a friendly environment for developing
sophisticated application software. The great software support
that Moxa provides makes the programmer’s job easier, and helps
programmers develop bug-free code quickly and at a lower cost.
Overview
Appearance
› IEC 61850-3 compliant for power substation automation
systems (DPP-T models only)
› Intel Celeron M 1 GHz processor with 400 MHz FSB
› 1 x 200-pin DDR2 SO-DIMM socket supporting DDR2 400 up to
1 GB (512 MB built-in)
› Six 10/100 Mbps Ethernet ports
› 1 CompactFlash socket, 1 IDE ATA-150 connector for storage
expansion
› USB 2.0 ports for high speed peripherals
› 4 isolated RS-232 and 8 isolated RS-485 ports
› Serial port speed from 50 bps to 921.6 kbps (nonstandard
baudrates supported)
› Embedded Linux or Windows Embedded Standard 2009 OS
› 19-inch rackmount model, 1U height
› Dual 100/240 VAC/VDC power input (single power and dual
power models available)
› Fanless design
Front View
Power Fail 2
Power Fail 1
RS-232 RS-485
LED Indicators
LAN
Ready
Storage
19-inch
Rackmount Ear
LED Indicators
LED Indicators
EN : 60825
Rear View
19-inch
Rackmount Ear
10/100 Mbps Ethernet x 6
RS-232 Serial Port x 4, DB9
RS-485 Serial Port x 8,
Terminal Block
Reset ButtonVGA PS/2
USB 2.0
Host x 2
Power Input 1
Power Input 2
Power Switch
Award-winning Product
