Software Speciﬁcations

Linux

OS: Linux 2.6.18, Debian Etch 4.0

File System: EXT2

Internet Protocol Suite: TCP, UDP, IPv4, SNMPv1/v2c/v3, ICMP, ARP,

HTTP, CHAP, PAP, SSH 1.0/2.0, SSL, DHCP, NTP, NFS, Telnet, FTP,

TFTP, PPP, PPPoE

Internet Security: OpenVPN, iptables ﬁrewall

Web Server (Apache): Allows you to create and manage web sites;

supports PHP and XML

Terminal Server (SSH): Provides secure encrypted communications

between two un-trusted hosts over an insecure network

Dial-up Networking: PPP Daemon for Linux that allows Unix machines

to connect to the Internet through dialup lines, using the PPP protocol,

as a PPP server or client. Works with ‘chat’, ‘dip’, and ‘diald’, among

(many) others. Supports IP, TCP, UDP, and (for Linux) IPX (Novell).

File Server: Enables remote clients to access ﬁles and other resources

over the network

Watchdog: Features a hardware function to trigger system reset in a

user speciﬁed time interval (Moxa API provided)

Application Development Software:

• Moxa API Library (Watchdog timer, Moxa serial I/O control)

• GNU C/C++ cross-compiler

• GNU C library

• Perl

Windows XP Embedded

OS: Windows Embedded Standard 2009

File System: NTFS

Internet Protocol Suite: DHCP, DNS, FTP, HTTP, SNTP, NTP, Telnet,

SMTP, SNMPv2, TCP, UDP, IPv4, ICMP, IGMP, IPsec, TAPI, ICS, PPP,

CHAP, EAP, PPPoE, PPTP, NetBIOS

Web Server (IIS): Allows users to create and manage websites

Remote Registry Service: Enables remote users to modify registry

settings on this computer

Watchdog: Features a hardware function to trigger system reset in a

user speciﬁed time interval (Moxa API provided)

Enhanced Writer Filter: Redirect disk write operations to volatile

(RAM) or non-volatile (disk) storage

Application Development Software:

• Moxa API Library

• Microsoft .Net Framework 3.5 with SP 1

• Active Directory Service Interface (ADSI) Core

• Active Template Library (ATL)

• Common Control Libraries

• Common File Dialogs

• Direct3D, DirectPlay, DirectShow, and Direct show lters

• Mapi32 Libraries

• Message Queuing (MSMQ) Core

• Microsoft Visual C++ Run Time Libraries

• Power Management dynamic-link library

• RPC

• Windows API, Script Engines, and WMI

Model Name

Serial Ports LAN Ports Storage

OS Power

IEC 61850-3

Certiﬁed

RS-232 RS-485 10/100 Mbps SATA CF USB

DA-681-I-SP-XPE

4 8 6

P P P

WES 2009 Single –

DA-681-I-SP-LX

4 8 6

P P P

Linux Single –

DA-681-I-DP-XPE

4 8 6

P P P

WES 2009 Dual –

DA-681-I-DP-LX

4 8 6

P P P

Linux Dual –

DA-681-I-DPP-T-XPE

4 8 6

P P P

WES 2009 Dual

DA-681-I-DPP-T-LX

4 8 6

P P P

Linux Dual

Available Models

DA-681-I-SP-XPE: x86 rackmount computer with VGA, 6 Ethernet ports, 4 RS-232 ports, 8 RS-485

ports, CompactFlash, SATA, USB, Single Power, WES 2009, -10 to 60°C operating temperature

DA-681-I-SP-LX: x86 rackmount computer with VGA, 6 Ethernet ports, 4 RS-232 ports, 8 RS-485

ports, CompactFlash, SATA, USB, Single Power, Linux 2.6, -10 to 60°C operating temperature

DA-681-I-DP-XPE: x86 rackmount computer with VGA, 6 Ethernet ports, 4 RS-232 ports, 8 RS-485

ports, CompactFlash, SATA, USB, Dual Power, WES 2009, -10 to 60°C operating temperature

DA-681-I-DP-LX: x86 rackmount computer with VGA, 6 Ethernet ports, 4 RS-232 ports, 8 RS-485

ports, CompactFlash, SATA, USB, Dual Power, Linux 2.6, -10 to 60°C operating temperature

DA-681-I-DPP-T-XPE: IEC 61850-3 x86 ready-to-run rackmount computer with VGA, 6 Ethernet

ports, 4 RS-232 ports, 8 RS-485 ports, CompactFlash, SATA, USB, dual power, WES 2009, -40 to 75°C operating temperature

DA-681-I-DPP-T-LX: IEC 61850-3 x86 ready-to-run rackmount computer with VGA, 6 Ethernet ports, 4 RS-232 ports, 8 RS-485 ports, CompactFlash,

SATA, USB, dual power, Linux 2.6, -40 to 75°C operating temperature

Optional Accessories (can be purchased separately)

FK-76127-01: Hard disk installation package

Ordering Information

Package Checklist

• DA-681 embedded computer

• Rackmount kit

• Ethernet cable: RJ45 to RJ45 cross-over

cable, 100 cm

• Documentation and software CD or DVD

• Quick installation guide (printed)

• Warranty card
