DA-681 Linux Software Configuration
2-8
# !/bin/sh
# Add the daemonyou want to run daemon
/root/tcps2-release &
5. After you finish writing or modifying the code, remember to execute “umount /” to change the root directory
back to Read-only mode.
Moxa:~# umount /
6. You should be able to find the enabled daemon after you reboot the system.
Moxa:~# ps -ef
UID PID PPID C STIME TTY TIME CMD
root 1 0 0 Feb18 ? 00:00:01 init [2]
root 2 1 0 Feb18 ? 00:00:00 [migration/0]
root 3 1 0 Feb18 ? 00:00:00 [ksoftirqd_0]
root 4 1 0 Feb18 ? 00:00:00 [events/0]
root 5 1 0 Feb18 ? 00:00:00 [khelper]
root 6 1 0 Feb18 ? 00:00:00 [kthread]
root 9 6 0 Feb18 ? 00:00:00 [kblockd/0]
root 10 6 0 Feb18 ? 00:00:00 [kacpid]
root 107 6 0 Feb18 ? 00:00:00 [kseriod]
root 143 6 0 Feb18 ? 00:00:00 [pdflush]
root 144 6 0 Feb18 ? 00:00:00 [pdflush]
root 145 6 0 Feb18 ? 00:00:00 [kswapd0]
root 146 6 0 Feb18 ? 00:00:00 [aio/01]
root 622 6 0 Feb18 ? 00:00:00 [khubd]
root 763 6 0 Feb18 ? 00:00:00 [scsi_eh_0]
root 765 6 0 Feb18 ? 00:00:00 [usb-storage]
root 1119 1 0 Feb18 ? 00:00:00 udevd --daemon
root 1527 6 0 Feb18 ? 00:00:00 [kpsmoused]
root 1754 6 0 Feb18 ? 00:00:00 [kmirrord]
daemon 2094 1 0 Feb18 ? 00:00:00 /sbin/portmap
root 2311 1 0 Feb18 ? 00:00:00 /usr/sbin/acpid
-c /etc/acpi/evemts –s /var/run/acpid.socket
root 2318 1 0 Feb18 ? 00:00:00 /usr/sbin/inetd
root 2452 1 0 Feb18 ? 00:00:00 /root/tcps2-release
Setting the Run-Level
To set the Linux run-level and execution priority of a program, use the following command (because the root
file system is mounted in Read-only mode, we need to re-mount it with write permission).
Moxa:~# mount -o remount,rw /dev/hda1 /
Edit a shell script to execute /root/tcps2-release and save to tcps2 as an example. This program can be
found in Example Directory in CD-ROM.
#cd /etc/rc2.d
#ln –s /etc/root/tcps2 S60tcps2
or
#ln –s /etc/root/tcps2 k30tcps2
