DA-681 Linux Managing Communications
3-21
for the DA-681-LX without worrying about the amount of disk space that will be available. The DA-681-LX
supports only NFS client protocol.
ATTENTION
Click on the following links for more information about NFS.
•
http://www.tldp.org/HOWTO/NFS-HOWTO/index.html
•
http://nfs.sourceforge.net/nfs-howto/client.html
The following procedures illustrate how to mount a remote NFS Server.
1. Scan the NFS Server’s shared directory.
#showmount –e HOST
showmount: Show the mount information of an NFS Server
-e: Show the NFS Server’s export list.
HOST: IP address or DNS address
2. Establish a mount point on the NFS Client site.
#mkdir –p /home/nfs/public
3. Mount the remote directory to a local directory.
#mount –t nfs 192.168.3.100/home/public /home/nfs/public
This is where 192.168.3.100 is the example IP address of the NFS server.
SNMP (Simple Network Management Protocol)
The DA-681-LX comes with the SNMP V1 (Simple Network Management Protocol) agent software pre-installed.
It supports RFC1317 RS-232 like group and RFC 1213 MIB-II. The following example shows an SNMP agent
responding to a query from the SNMP browser on the host site:
***** SNMP QUERY STARTED *****
[root@jaredRH90 root]# snmpwalk -v 1 -c public 192.168.30.128|more
SNMPv2-MIB::sysDescr.0 = STRING: Linux Moxa 2.6.18-5-686 #1 SMP Mon Dec 24 16:41
:07 UTC 2007 i686
SNMPv2-MIB::sysObjectID.0 = OID: SNMPv2-SMI::enterprises.8691.12.680
SNMPv2-MIB::sysUpTime.0 = Timeticks: (134544) 0:22:25.44
SNMPv2-MIB::sysContact.0 = STRING: "Moxa Inc."
SNMPv2-MIB::sysName.0 = STRING: Moxa
SNMPv2-MIB::sysLocation.0 = STRING: "Fl.8, No.6, Alley 6, Lane 235, Pao-Chiao Rd
. Shing Tien City, Taipei, Taiwan, R.O.C."
SNMPv2-MIB::sysORLastChange.0 = Timeticks: (12) 0:00:00.12
SNMPv2-MIB::sysORID.1 = OID: IF-MIB::ifMIB
SNMPv2-MIB::sysORID.2 = OID: SNMPv2-MIB::snmpMIB
SNMPv2-MIB::sysORID.3 = OID: TCP-MIB::tcpMIB
SNMPv2-MIB::sysORID.4 = OID: IP-MIB::ip
SNMPv2-MIB::sysORID.5 = OID: UDP-MIB::udpMIB
SNMPv2-MIB::sysORID.6 = OID: SNMP-VIEW-BASED-ACM-MIB::vacmBasicGroup
SNMPv2-MIB::sysORID.7 = OID: SNMP-FRAMEWORK-MIB::snmpFrameworkMIBCompliance
SNMPv2-MIB::sysORID.8 = OID: SNMP-MPD-MIB::snmpMPDCompliance
SNMPv2-MIB::sysORID.9 = OID: SNMP-USER-BASED-SM-MIB::usmMIBCompliance
SNMPv2-MIB::sysORDescr.1 = STRING: The MIB module to describe generic objects fo
r network interface sub-layers
SNMPv2-MIB::sysORDescr.2 = STRING: The MIB module for SNMPv2 entities
SNMPv2-MIB::sysORDescr.3 = STRING: The MIB module for managing TCP implementatio
...
SNMPv2-MIB::snmpOutBadValues.0 = Counter32: 0
SNMPv2-MIB::snmpOutGenErrs.0 = Counter32: 0
