DA-681 Linux System Recovery
4-2
Recovery Environment
The recovery environment includes the DA-681-LX embedded computer and a bootable USB disk with the
recovery programs and system image file.
Recovery Procedure
1. Format an Empty USB Disk.
a. Prepare a USB disk that has at least a 256 MB capacity.
b. Format your USB disk with the HP USB Disk Format Tool. Open the utility and select the device and
FAT file system. You need empty disk only. DO NOT check the option Create a DOS startup disk.
c. Click Start.
ATTENTION
The
HP USB Disk Storage Format Tool can be downloaded from many web sites. Do a search on
HP USB Disk
Storage Format Tool
from any search engine to locate the tool.
2. Create a Linux Bootable USB Disk.
a. You can find the firmware directory in the Recovery CD shipped with the DA-681-LX computer.
b. Configure Windows Explorer to show hidden files (including protected operating system files).
c. Copy all files in the firmware directory to the root directory of your USB disk.
d. Open a DOS prompt and type M:\syslinux.exe M: to create a bootable Linux disk. In this example, M:
is the USB Disk drive number.
3. Set up the BIOS to Boot from a USB Disk.
a. Insert the USB disk.
Bootable USB
DISK
(recovery
DA-681-LX
USB Port
