Power Computers
2
www.moxa.com
Rear View (DA-662A-8)
RS-232/422/485 Serial Ports x 8
RJ45, 50 bps to 921.6 kbps
10/100 Mbps Ethernet, RJ45 x 2
RS-232 Console Port
ON/OFF Switch
ON/OFF Switch
Power Input, 100 to 240 VAC
Rear View (DA-662A-16)
RS-232/422/485 Serial Ports x 16
RJ45, 50 bps to 921.6 kbps
10/100 Mbps Ethernet, RJ45 x 4
Power Input, 100 to 240 VAC
RS-232 Console Port
Hardware Specifications
Computer
CPU: MoxaMacro 500 MHz
OS: Embedded Linux (pre-installed)
DRAM: 128 MB onboard
Flash: 32 MB onboard
Ethernet Interface
LAN: 4 auto-sensing 10/100 Mbps ports (RJ45)
Magnetic Isolation Protection: 1.5 kV built-in
Serial Interface
Serial Standards: 8 to 16 RS-232/422/485 ports, software selectable
(8-pin RJ45)
ESD Protection: 8 kV contact, 15 kV Air ESD protection for all signals
Surge Protection: 2 kV line-to-line and 4 kV line-to-ground surge
protection, 8/20 μs waveform (DA-662A-I-8/16-LX only)
Insulation: 500 V (DA-662A-I-8/16-LX only)
Isolation: 2 kV digital isolation (DA-662A-I-8/16-LX only)
Termination Resistor: 120 ohm, jumper selectable
Console Port: RS-232 (all signals), RJ45 connector
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 Kbps (supports non-standard baudrates;
see user’s manual for details)
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
(DA-662A-I-8/16-LX only: TxD, RxD, RTS, CTS, GND)
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
LEDs
System: OS Ready
LAN: 10/100M x 4
Serial: TxD, RxD (16 of each)
Mini Screen with Push Buttons
LCD Panel: Liquid Crystal Display on the case, 2 x 16 text mode
Push Buttons: Four membrane buttons for convenient on-site
configuration
Physical Characteristics
Housing: SECC sheet metal (1 mm)
Weight: 4.3 kg
Dimensions:
Without ears: 440 x 45 x 237 mm (17.32 x 1.77 x 9.33 in)
With ears: 480 x 45 x 237 mm (18.90 x 1.77 x 9.33 in)
Mounting: Standard 19-inch rackmount
Environmental Limits
Operating Temperature: -10 to 60°C (14 to 140°F)
Storage Temperature: -20 to 80°C (-4 to 176°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-Vibration: 1 g @ IEC-68-2-6, sine wave (resonance search),
5-500 Hz, 1 Oct/min, 1 Cycle, 13 mins 17 sec per axis
Power Requirements
Input Voltage: 100 to 240 VAC auto ranging
(47 to 63 Hz for AC input)
Power Consumption: 20 W
Standards and Certifications
Safety: UL 60950-1
EMC:
EN 55022/24
CISPR 22, FCC Part 15B Class A
IEC 61000-4-2 ESD: Contact 8 kV; Air 15 kV
IEC 61000-4-3 RS: 3 V/m (80 MHz to 1 GHz)
IEC 61000-4-4 EFT: Power 1 kV; Signal 0.5 kV
IEC 61000-4-5 Surge: Power 2 kV; Signal 4 kV
IEC 61000-4-6 CS: 3 V
IEC 61000-4-8
IEC 61000-4-11
Green Product: RoHS, CRoHS, WEEE
Reliability
Alert Tools: Built-in buzzer and RTC (real-time clock)
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
MTBF (mean time between failures):
125,733 hrs
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
