UC-7101/7110/7112 Software User’s Manual Introduction
1-4
340 mA @ 12 VDC, 4.5W (UC-7110/7112)
Operating temperature
-10 to 60
o
C, (14 to 140
o
F), 5 to 95% RH
Storage temperature
-20 to 80
o
C, (-4 to 176
o
F), 5 to 95% RH
Regulatory Approvals
EMC: FCC Class A, CE Class A
Safety: UL, CUL, TÜV
Warranty
5 years
Software Specifications
Kernel
µClinux Kernel 2.6
Support for dynamic driver module load / unload
Protocol Stack
ARP, ICMP, IPV4, TCP, UDP, FTP, Telnet, SNMP V1/V2c, HTTP,
CHAP, PAP, DHCP, NTP, NFS V2/V3, SMTP, Telnet, FTP, PPP,
PPPoE
File System
JFFS2 for Kernel, Root File System (Read Only) and User Directory
(Read / Write)
Msh
Minix shell command
pppd
Dial in/out over serial port daemon
PPPoE
Point-to-Point over Ethernet daemon
snmpd
SNMP V1/V2c Agent daemon
busybox
Linux normal command utility
Tinylogin
login and user manager utility
Telnetd
Telnet server daemon
telnet
Telnet client program
inetd
TCP server manager program
ftpd
FTP server program
ftp
FTP client program
boa
Web server daemon
ntpdate
Network Time Protocol client utility
Tool Chain
Linux Tool Chain
Arm-elf-gcc (V2.95.3): C/C++ PC Cross Compiler
uClibc (V0.9.26): POSIX standard C library
