6-2 Press numeric keys 0-9 to select a new MIDI controller. You can also use the +/- switches to increase or

decrease the value of the number.

Note: * If you do nothing for 5 seconds, the LED will return to show the current PROGRAM CHANGE number.

* If the number you press is not in the range of defined numbers, the previous number will be retained.

* When you assign 120 or 121 as the MIDI controller for the WHEEL, you should move the

MODULATION Wheel to the mid-value then return it to the minimum value to send a relative MIDI message.

7. TRANSPOSE

This function allows you to shift the pitch of the unit in semitones. You can transpose the pitch by 24 half steps (12 up, 12

down).

7-1 Press the X’POSER switch. The LED shows the current TRANSPOSE value.

7-2 Press the “+” or “-” switch to change the TRANSPOSE value. Each time you press + or -, the keyboard is

transposed an additional half step.

* Pressing the + and - switches simultaneously resets the pitch to the default value.

Note: Turning the power off always resets the shifted pitch to the default value.

8. OCTAVE CHANGE

This function allows you to shift the pitch up to three octaves higher or two lower.

8-1 Press the OCTAVE UP or DOWN to change the octave range. The LED shows the new OCTAVE value.

* Press OCTAVE UP and DOWN switches simultaneously to reset the pitch to the default value.

Note: if the UP or DOWN switch is not pressed for 5 seconds, the LED will return to show the PROGRAM CHANGE

number.

9. Sending a PROGRAM CHANGE number

Using the PROGRAM switch and the numeric keys, you can send any MIDI PROGRAM CHANGE from 0-127.

9-1 Press the PROGRAM switch. The LED starts to flash showing the current PROGRAM number.

9-2 Press the numeric keys to alter the PROGRAM CHANGE number. You can also use the “+” or “-” keys to

change the value.

Note: * if you don’t do anything for 5 seconds the LED stops flashing and shows the current PROGRAM CHANGE

number.

* if the number you press is larger than 127, it will return to the previous PROGRAM CHANGE number.

10. Sending BANK MSB and LSB message

You can send any value of MSB or LSB from 0-127.

10-1 Press the CHANNEL and PROGRAM switches simultaneously. The LED starts to flash showing the current value

of the LSB. Press the numeric keys to change the LSB value. You can also use the “+” or “-” switches to change

the value.

10-2 Press the PROGRAM and MEMORY switches simultaneously. The LED starts to flash showing the current

value of the MSB. Press numeric keys to change the MSB value. You can also use the “+” or “-” switches to change

the value.

Note: * if you don’t do anything for 5 seconds the LED stops flashing and shows the current PROGRAM CHANGE

number.

* if the number you input is over 127, it will return to the previous LSB or MSB value.
