www.moxa.com
info@moxa.com
Modules & Boards
EM-1240 Series
RISC ready-to-run embedded core modules with 4 serial ports,
dual LANs, SD
The EM-1240 embedded module features 4 RS-232/422/485 serial
ports, dual Ethernet ports, and an SD socket for external storage
expansion. The modules have a compact design that can be easily
integrated with industrial applications such as gas stations, vending
machines, and ticketing machines, and offer a powerful serial
communication capability for better system integration. Programmers
will find that the pre-installed, ready-to-run μClinux platform and
the full-function development kit make it easy to develop software
and build a reliable communication base for industrial automation
applications. In addition, a wide temperature model is also available to
provide a reliable solution for harsh environments.
Overview
Appearance
› MOXA ART ARM9 32-bit 192 MHz processor
› 16 MB RAM, 8 MB flash disk onboard
› 4 software-selectable RS-232/422/485 serial ports
› Dual 10/100 Mbps Ethernet ports for network redundancy
› SD signals supported for external SD socket connection
› Built-in RTC, buzzer
› 10 GPIOs reserved for system integration
› Ready-to-run μClinux Kernel 2.6 platform
› Full-function development kit for quick evaluation and application
development
› -40 to 75°C wide temperature models available
EM-1240 Embedded Module
EM-1240 Embedded Module
Bottom View
Development Kit
MOXA ART ARM9 32-bit
Communication Processor
Onboard Intel NOR Flash 8 MB
onboard Flash 16 MB
LAN Port 1
LAN Port 2
Power Input
EM-1240
Embedded Module
Serial Port 1
Serial Port 2
Top View
Serial Port 3
Serial Port 4
Console Port
