www.moxa.com
info@moxa.com
Modules & Boards
EM-2260 Embedded Module
EM-2260 Series
RISC embedded core modules with 4 serial port DI/DO,
dual LANs, VGA, CompactFlash, USB
The EM-2260 embedded module features 4 RS-232/422/485 serial
ports, dual Ethernet ports, an EIDE interface for designing an external
storage connection, such as a CompactFlash socket and USB port
signals. The module has a compact design that is easily integrated
with a variety of industrial applications, including gas stations, vending
machines, and ticketing machines, and offers a powerful serial
communication capability for better system integration. Programmers
will find the pre-installed, ready-to-run Windows CE 6.0 platform and
full-function development kit a great benefit to developing software
and building reliable communication bases for industrial automation
applications.
The EM-2260 embedded module uses the Cirrus Logic EP9315 ARM9,
32-bit, 200 MHz RISC CPU. This powerful computing engine supports
several useful communication functions, but will not generate a lot
of heat. The built-in 32 MB NOR Flash ROM and 128 MB SDRAM
give you enough memory to run your application software directly on
the EM-2260. With its built-in VGA output interface, the EM-2260 is
suitable for use with SCADA systems in industrial applications, such
as manufacturing automation, production line process monitoring, and
mining automation, that require VGA and HMI features.
The EM-2260 Development Kit provides users with a handy tool for
first time evaluation to test the functionality of the embedded core
module. It has several peripherals built-in, including RS-232/422/485
ports and digital input and output, making it suitable for developing a
variety of industrial applications.
Cirrus Logic EP9315 ARM9 CPU
EM-2260 Embedded Module
onboard 128 MB RAM onboard 32 MB Flash
CN1 CN2
Overview
Appearance
› Cirrus Logic EP9315 ARM9 CPU, 200 MHz
› 128 MB RAM on-board, 32 MB flash disk
› Graphical interface for external VGA output connection
› 2 kV optically isolated RS-232/422/485 serial ports
› Dual 10/100 Mbps Ethernet for network redundancy
› 8 DI and 8 DO channels
› Supports CompactFlash and USB 2.0 hosts
› Ready-to-run WinCE 6.0 platform
› Full-function development kit for quick evaluation and application
development
