IA240/241 Linux User’s Manual Getting Started
2-2
Powering on the IA240/241
Connect the SG wire to the shielded contact located in the upper left corner of the IA240/241, and
then power on the computer by connecting it to the power adaptor. It takes about 30 to 60 seconds
for the system to boot up. Once the system is ready, the Ready LED will light up.
NOTE After connecting the IA240/241 to the power supply, it will take about 30 to 60 seconds for the
operating system to boot up. The green Ready LED will not turn on until the operating system is
ready.
ATTENTION
This product is intended to be supplied by a Listed Power Unit and output marked with “LPS”
and rated 12-48 VDC, 580 mA (minimum requirements).
Connecting the IA240/241 to a PC
There are two ways to connect the IA240/241 to a PC: through the Serial Console port or via
Telnet over the network.
Serial Console
The serial console port gives users a convenient way of connecting to the IA240/241’s console
utility. This method is particularly useful when using the computer for the first time. The signal is
transmitted over a direct serial connection, so you do not need to know either of its two IP
addresses in order to connect to the serial console utility.
Use the serial console port settings shown below.
Baudrate
115200 bps
Parity
None
Data bits
8
Stop bits:
1
Flow Control
None
Terminal
VT100
Once the connection is established, the following window will open.
