Compact/Fanless Computers
2
www.moxa.com
Hardware Specifications
Computer
CPU: Cirrus EP9315 ARM9 CPU, 200 MHz
USB: USB 2.0 hosts x 2, type A connector
DRAM: DDR2 SDRAM, 128 MB
Flash: NOR Flash, 32 MB
OS (pre-installed): Linux or Windows CE 6.0
Storage
Storage Expansion: CF card type I/II
Display
Graphics Controller: EP9315 internal graphics accelerator engine with
TTL graphical signal support
Display Memory: Dynamic video memory (shares system memory)
Display Interface: CRT interface for VGA output, DB15 female
connector
Resolution: 1024 x 768, 8 bits
Ethernet Interface
LAN: Auto-sensing 10/100 Mbps ports (RJ45) x 2
Magnetic Isolation Protection: 1.5 kV built-in
Serial Interface
Serial Standards: RS-232/422/485 ports, software-selectable (DB9
male) x 4
ESD Protection: 4 kV for all signals
Console Port: RS-232 (TxD, RxD, GND), 4-pin header output (115200,
n, 8, 1)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 kbps (supports nonstandard baudrates; see
user’s manual for details)
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
Digital Input
Input Channels: DI x 8
Input Voltage: 0 to 30 VDC
Digital Input Levels for Dry Contacts:
• Logic level 0: Close to GND
• Logic level 1: Open
Digital Input Levels for Wet Contacts:
• Logic level 0: +3 V max.
• Logic level 1: +10 V to +30 V (COM to DI)
Connector Type: 10-pin screw-fastened terminal block (8 points, COM,
GND)
Isolation: 3 kV optical isolation
Digital Output
Output Channels: DO x 8, sink type
Output Current: Max. 200 mA per channel
On-State Voltage: 24 VDC nominal, open collector to 30 V
Connector Type: 9-pin screw-fastened terminal block
Isolation: 3 kV optical isolation
LEDs
System: Power, Ready, Storage
LAN: 10M/Link x 2, 100M/Link x 2 (on connector)
Serial: TxD x 4, RxD x 4
Switches and Buttons
Reset Button: Supports “Reset to Factory Default”
Physical Characteristics
Housing: Aluminum, industrial vertical form factor
Weight: 1 kg (2.22 lb)
Dimensions: 52 x 112.6 x 162 mm (2.05 x 4.43 x 6.38 in)
Mounting: DIN-rail, wall
Environmental Limits
Operating Temperature:
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature:
Standard Models: -20 to 80°C (-4 to 176°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-Vibration: 2 Grms @ IEC-68-2-34, random wave, 5-500 Hz, 1 hr
per axis
Anti-Shock: 20 g @ IEC-68-2-27, half sine wave, 11 ms
Power Requirements
Input Voltage: 12 to 48 VDC (3-pin terminal block)
Input Current:
With no load on USB ports:
• 240 mA @ 24 VDC
• 480 mA @ 12 VDC
With full load on USB ports:
• 450 mA @ 24 VDC
• 900 mA @ 12 VDC
Power Consumption:
With no load on USB ports: 5.8 W
With full load on USB ports: 11 W
Standards and Certifications
Safety: UL 60950-1, CSA C22.2 No. 60950-1-03, EN 60950-1, CCC
(GB4943, GB9254, GB17625.1)
EMC: EN 55022 Class A, EN 61000-3-2 Class A, EN 61000-3-3, EN
55024, FCC Part 15 Subpart B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 1 kV; Signal: 1 kV
IEC 61000-4-6 CS: Signal: 3 V/m
IEC 61000-4-8 1 A/m
IEC 61000-4-11
Green Product: RoHS, CRoHS, WEEE
Reliability
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
MTBF (mean time between failures)
Time: 145,328 hrs
Standard: Telcordia (Bellcore) Standard
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Note: The Hardware Specications apply to the embedded computer unit itself,
but not to accessories. In particular, the wide temperature specication does not
apply to accessories such as the power adapter and cables.
