IA260-261-262 EM-2260 LX User’s Manual Managing Communications
6. Set up DNS
If you are using DNS servers supplied by your ISP, edit the file
/etc/resolv.conf by adding the following lines of code:
nameserver ip_addr_of_first_dns_server
nameserver ip_addr_of_second_dns_server
For example:
nameserver 168..95.1.1
nameserver 139.175.10.20
7. Use the following command to create a pppoe connection:
pppd eth0
The eth0 is what is connected to the ADSL modem LAN port. The example above uses LAN1.
To use LAN2, type:
pppd eth1
8. Type ifconfig ppp0 to check if the connection is OK or has failed. If the connection is OK,
you will see information about the ppp0 setting for the IP address. Use ping to test the IP.
9. If you want to disconnect it, use the kill command to kill the pppd process.
NFS (Network File System)
The Network File System (NFS) is used to mount a disk partition on a remote machine, as if it
were on a local hard drive, allowing fast, seamless sharing of files across a network. NFS allows
users to develop applications for the IA260/IA261/IA262/EM-2260, without worrying about the
amount of disk space that will be available. The IA260/IA261/IA262/EM-2260 supports NFS
protocol for client.
NOTE Click on the following links for more information about NFS:
http://www.tldp.org/HOWTO/NFS-HOWTO/index.html
Setting up the IA260/IA261/IA262/EM-2260 as an NFS Client
The following procedure is used to mount a remote NFS Server.
1. To know the NFS Server’s shared directory.
2. Establish a mount point on the NFS Client site.
3. Mount the remote directory to a local directory.
#mkdir –p /home/nfs/public
#mount –t nfs NFS_Server(IP):/directory /mount/point
Example
#mount –t nfs 192.168.3.100:/home/public /home/nfs/public
4-18
