DIN-Rail Computers
Hardware Specifications
Computer
CPU: Cirrus EP9315 ARM9 CPU, 200 MHz
OS (pre-installed): Windows CE 6.0 or Linux
DRAM: 128 MB onboard
Flash: 32 MB onboard
USB: USB hosts x 2, compliant with USB 2.0 (OHCI) type A connectors
Storage
Storage Expansion: CompactFlash slot
Display
Graphics Controller: EP9315 internal graphics accelerator engine with
TTL graphical signal support
Display Memory: Dynamic video memory (shares system memory)
Display Interface: CRT interface for VGA output, DB15 female
connector
Resolution: 1024 x 768, 8 bits
Ethernet Interface
LAN: 2 auto-sensing 10/100 Mbps ports (RJ45)
Magnetic Isolation Protection: 1.5 KV built-in
Serial Interface
Serial Standards: 2 or 4 RS-232/422/485 ports, software-selectable
(DB9 male)
ESD Protection: 4 KV for all signals
Isolation: 2 KV digital isolation
Console Port: RS-232 (TxD, RxD, GND), 4-pin header output (115200,
n, 8, 1)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 Kbps (supports non-standard baudrates;
see user's manual for details)
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
Digital Input
Input Channels: 8, source type
Input Voltage: 0 to 30 VDC
Digital Input Levels for Dry Contacts:
• Logic level 0: Close to GND
• Logic level 1: Open
Digital Input Levels for Wet Contacts:
• Logic level 0: +3 V max.
• Logic level 1: +10 V to +30 V (COM to DI)
Connector Type: 10-pin screw terminal block (8 points, COM, GND)
Isolation: 3 KV optical isolation
Digital Output
Output Channels: 8, sink type
Output Current: Max. 200 mA per channel
On-state Voltage: 24 VDC nominal, open collector to 30 V
Connector Type: 9-pin screw terminal block (8 points, GND)
Isolation: 3 KV optical isolation
CANbus Communication (IA262 CE models only)
Interface: Dual optically isolated CAN2.0A/2.0B compliant ports
CAN Controller: Phillips SJA1000T
Signals: CAN-H, CAN-L
Isolation: 2 KV digital isolation
Speed: 10 Kbps to 1 Mbps
Connector Type: DB9 male
LEDs
System: Power, Ready, Storage
LAN: 10M/Link x 2, 100M/Link x 2 (on connector)
Serial: TxD x 4, RxD x 4
IA261-I: P1 to P4 for serial ports
IA262-I: P1 to P2 for serial ports, P3 to P4 for CAN ports
Switches and Buttons
Reset Button: Supports "Reset to Factory Default"
Physical Characteristics
Housing: Aluminum, industrial vertical form factor
Weight: 950 g
Dimensions: 60 x 115 x 152 mm (2.36 x 4.53 x 5.98 in)
Mounting: DIN-Rail, wall
Environmental Limits
Operating Temperature:
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature:
Standard Models: -20 to 80°C (-4 to 176°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-vibration: 5 g rms @ IEC-68-2-34, random wave, 5-500 Hz, 1 hr
per axis
Anti-shock: 50 g @ IEC-68-2-27, half sine wave, 11 ms
Power Requirements
Input Voltage: Redundant power input design
PWR1: 12 to 48 VDC (3-pin terminal block)
PWR2: 12 to 48 VDC (power jack with thread)
Power Consumption:
With no load on USB ports: 5.8 W
• 240 mA @ 24 VDC
• 480 mA @ 12 VDC
With full load on USB ports: 11 W
• 450 mA @ 24 VDC
• 900 mA @ 12 VDC
Standards and Certifications
Safety: UL 60950-1, CSA C22.2 No. 60950-1-03, EN 60950-1
EMC: EN 61000-6-4, EN 61000-3-2 Class D, EN 61000-3-3, EN
61000-6-2, FCC Part 15 Subpart B Class A
Green Product: RoHS, CRoHS, WEEE
Reliability
Alert Tools: Built-in buzzer and RTC (real-time clock)
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
MTBF (mean time between failures):
IA261-I: 118,752 hrs
IA261-I: 131,832 hrs
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Note: The Hardware Specications apply to the embedded computer unit itself,
but not to accessories. In particular, the wide temperature specication does not
apply to accessories such as the power adaptor and cables.
