V2400A Series Expansion Modules Software Installation and Programming Guide

4-25

The following example is for OPEN/WEP/WPA/WPA2 AP.

ctrl_interface=/var/run/wpa_supplicant

ctrl_interface_group=wheel

update_config=1

### Open system ###

#network={

# ssid="Open"

# key_mgmt=NONE

###################

##### WEP #####

#network={

# ssid="WEP-ssid"

# bssid=XX:XX:XX:XX:XX:XX

# key_mgmt=NONE

# wep_key0=KEY

###############

##### WPA/WPA2 PSK #####

#network={

# ssid="WPA-ssid"

# proto=WPA WPA2 RSN

# key_mgmt=WPA-PSK

# pairwise=TKIP CCMP

# group=TKIP CCMP

# psk="KEY"

#######################

The basic command to connect for WPA-supplicant is:

root@Moxa:~# wpa_supplicant -i <interface> -c <configuration file> -B

The -B option should be included because it forces the supplicant to run in the background.

1. Connect with the following command after editing the wpa_supplicant.conf file:

root@Moxa:~# wpa_supplicant -i wlan0 -c /etc/wpa_supplicant.conf -B

2. Use iwconfig to check the connection status. The response you receive should be similar to the following:

wlan0 IEEE 802.11abgn ESSID:"MOXA_AP"

Mode:Managed Frequency:2.462 GHz Access Point: 00:1F:1F:8C:0F:64

Bit Rate=36 Mb/s Tx-Power=27 dBm

Retry min limit:7 RTS thr:off Fragment thr:off

Encryption key:1234-5678-90 Security mode:open

Power Management:off

Link Quality=37/70 Signal level=-73 dBm

Rx invalid nwid:0 Rx invalid crypt:0 Rx invalid frag:0

Tx excessive retries:0 Invalid misc:0 Missed beacon:0
