Moxa V2426A-C2-W7E [46/88] Cellular module pls8 x r3 and above

V2400A Series Expansion Modules Software Installation and Programming Guide

4-26

ATTENTION

For more information about wpa_supplicant.conf, go to the following websites:

http://www.daemon

-systems.org/man/wpa_supplicant.conf.5.html

http://linux.die.net/man/5/wpa_supplicant.conf

Cellular Module (PLS8-X R3 and Above)

The DK02/DK03 cards in the V2400A expansion modules are provided with two mini PCIe sockets in which cellular

modules can be installed. You can use the PLS8-X cellular modules with a V2400A-LX series expansion module.

Specifications of the cellular modules that you can use with the V2400A are available in the product datasheet.

Contact your sales representative for more information.

Once the cellular module is connected, use the V2400A-LX cellular connection utility

cell_mgmt to establish a

cellular connection. Commands to determine the signal strength, use the dial-up function on the V2400A-LX, and

other advanced functions are explained in the sections below:

Installing cell_mgmt

Copy the utility\LX\V2400A-pls8_cell_mgmt directory from the CD to the V2400A machine and install it.
