Moxa TC-6110-W7E Технические характеристики онлайн
Railway Computers
1
www.moxa.com
TC-6110 Series
› Durable, fanless design for rolling stock applications
› Modular design for easy storage and peripheral expansion
› Comes with Moxa SafeGuard™, for HDD in wide temperature and
high vibration environments
› Compact rackmount 3U housing, wide 24 to 110 VDC isolated
power supply
› Supports SNMP-based system configuration, control, and
monitoring
› Essential compliance with EN 50155*
› Conformal coating models available
*Moxa defines “essential compliance” to include those EN 50155 requirements
that make products more suitable for rolling stock railway applications.
Introduction
Appearance
TC-6110 train computers are designed specifically for car-borne train
automation like network video recorders, passenger information
systems, condition monitoring, and train-to-ground communications.
The computers come with two gigabit LAN ports, one RS-232 serial
port, three USB 2.0 ports, and two TC-SATA-T storage modules, giving
customers a versatile solution for on-board train computing.
Designed for high reliability in the demanding conditions experienced
in on-board train environments, TC-6110 computers come with M12
connectors on both the gigabit LAN ports and dual power inputs, and
an additional M12 USB port. The TC-6000 Series expansion modules
further allow for highly flexible, convenient integration into a variety
of systems. Users can easily add storage modules for additional
capacity, gigabit switch modules to expand network connectivity and/
or bandwidth, serial and CAN bus modules for additional serial/CAN
device connectivity, or mini PCIe modules for additional peripheral
communications.
For the strongest component protection in harsh environments, TC-
6110 Series computers are available with conformal coating.
EN 50155-compliant x86 train computer with dual LAN ports, dual power
inputs, USB, VGA, serial port, CompactFlash, and 4 expansion slots
EN : 60825
Power Input 1
(M12)
Power Input 2
(M12)
10/100/1000 Mbps
LAN x 2 (M12)
USB 2.0 Hosts x 1 (M12)
VGA
RS-232 x 1
(DB9)
GPS antenna x 1
Audio in/out x 1 (M12)
USB 2.0 Hosts x 2
(Type A)
LED x 12
(LAN, Power, Serial,
Programmable)
Remote Power Switch
Power LED
Power LED
Grounding Connector
Reset Button
Storage Module LEDs
Hot-Swap Buttons
Expansion Modules
(Slot 1 / Slot 2 / Slot 3 / Slot 4)
TC-SATA-T Storage Modules
(Slot 1 / Slot 2)
