Railway Computers
2
www.moxa.com
Hardware Specifications
Computer
CPU: Intel Atom D525, dual-core 64-bit threaded 1.8 GHz, 1 MB for L2
cache
OS: Windows Embedded Standard 7 or Linux
Note: The OS is pre-installed.
System Chipset: ICH8-M
System Memory: 4 GB capacity, 2 GB pre-installed: 2 slots of 2 GB
DDR3-1066 204 pin SO-DIMM SDRAM
USB: USB 2.0 hosts x 3 (Type A connectors x 2, supporting system
boot up; D-coded, 5-pin, female M12 connectors x 1)
Storage
Built-in: 8 GB onboard industrial CompactFlash card for operating
system storage
HDD Support: 2 removable TC-SATA-T storage trays, for 2.5-inch SSD
or HDD storage drive (with Intelligent Heating Solution)
Other Peripherals
Audio: 1 line in / line out interface with A-coded, 8-pin, female M12
connector
Independent Sensors: Accelerometer (G-sensor), thermometer
(T-sensor)
Display
Graphics Controller: Integrated Intel GMA 3150 (Pineview) Graphics
Engine
VGA Interface: Up to 2048 x 1536 resolution at 75 Hz, DB9 female
connector
Ethernet Interface
LAN: Auto-sensing 10/100/1000 Mbps ports (A-coded, 8-pin, female
M12) x 2
GPS Module
Receiver Types: 50 channels, GPS L1 C/A code, SBAS (WAAS),
EGNOS, MSAS, GAGAN
Acquisition:
• Cold start: 29 s
• Warm start: 29 s
• Aided start: 1 s
• Hot start: 1 s
Sensitivity:
• Tracking & Navigation: -160 dBm
• Reacquisition: -160 dBm
• Cold start: -147 dBm
Accuracy:
• Autonomous: 2.5 m
• SBAS: 2.0 m
Protocols: NMEA, UBX binary, max. update rate: 5 Hz (ROM version)
Time Pulse: 0.25 Hz to 1 kHz
Velocity Accuracy: 0.1 m/s
Heading Accuracy: 0.5°
A-GPS: AssistNow Online/Offline, SUPL (Open Mobile Alliance)
compliant
Operational Limits:
• Dynamics ≤ 4 g
• Altitude 50,000 m
• Velocity 500 m/s
Connector Type: QMA
WLAN Module (Available on request)
Standards: IEEE 802.11 a/b/g/n for wireless LAN
Security: WEP, TKIP, and AES hardware encryption
Antenna Type: 2 QMA connectors (female type)
Mode: Client (default), Access Point (available on request)
Serial Interface
Serial Standards: 1 RS-232 port (DB9 male)
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS
Baudrate: Up to 115.2 kbps
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
LEDs
System: Independent “Power” and “System Ready” signals
LAN: 100M/Link x 2, 1000M/Link x 2
Serial: TX x 1, RX x 1
Other: Programmable x 4
Physical Characteristics
Housing: Aluminum and SECC sheet metal (1 mm)
Weight: 5 kg (11.11 lb)
Dimensions:
• Without ears: 210 x 222 x 133 mm (8.27 x 8.74 x 5.24 in)
• With ears: 210 x 269 x 133 mm (8.27 x 10.60 x 5.24 in)
Mounting: Rack
Environmental Limits
Operating Temperature:
• Standard models: -25 to 55°C (-13 to 140°F), (EN 50155 Class T1)
• Wide temp. models: -40 to 70°C (-40 to 158°F), (EN 50155 Class Tx)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-Vibration: Meets EN 50155 standard
Anti-Shock: Meets EN 50155 standard
Power
Reset Button: For warm reboot (front panel)
Input Voltage: 24 to 110 VDC; A-coded, 5-pin, male M12 connector
Power Consumption: 32 W (without heater), 62 W (with heater), no
SSD/HDD attached
Note: 24 VDC and 110 VDC compliant with EN 50155
Standards and Certifications
Safety: UL 60950-1, CSA C22.2 No. 60950-1-07, EN 60950-1
EMC: EN 55022:2010 Class A, EN 55024:2010, FCC CFR Title 47 Part
15 Subpart B: 2011 Class A, CISPR 22:2008, ANSI C63.4:2009,
ICES-003 Issue 5:2012 Class A
RF: EN 62311:Jan 2008, ETSI EN 301 489-1:V1.9.2 (2011-09), ETSI
EN 301 489-3:V1.4.1 (2002-08), ETSI EN 301 893:V1.6.1 (2011-11),
ETSI EN 300 328:V1.7.1 (2006-10), ETSI EN 300 440-1:V1.6.1
(2010-08), ETSI EN 300 440-2:V1.4.1 (2010-08)
Rail Traffic: EN 50155:2007 (essential compliance*), EN 50121-
1:2006 for EMC test, EN 50121-3-2:2006, EN 50121-4:2006, EN
5011:2009+A1:2010, EN 61000-6-4:2007, CISPR 16-1-2:2003/
A2:2006, CISPR 16-2-1:2003+A1:2005, CISPR 16-2-3:2006, EN
60068-2-1:2007, EN 60068-2-2:2007, EN 61373:1999
*Moxa defines “essential compliance” to include those EN 50155 requirements
that make products more suitable for rolling stock railway applications.
Environmental Tests: EN 60068-2-1:2007, EN 60068-2-2:2007, EN
61373:1999
Reliability
Automatic Reboot Trigger: Built-in WDT (watchdog timer) supporting
system reset with software programmable time intervals of 1-255
MTBF (mean time between failures)
Time: 360,616 hrs
Standard: Telcordia (Bellcore) Standard TR/SR
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
Note: These hardware specifications describe the embedded computer unit itself,
but not its official accessories. In particular, the wide temperature specification
does not apply to accessories such as power adapters and cables.
