Moxa MC-7270-MP-T Технические характеристики онлайн
Marine Displays and Computers
1
www.moxa.com
MC-7200-MP-T
The MC-7200-MP-T marine computer is powered by the latest 3rd
generation Intel
®
Core
™
i7 3555LE processor, delivering a full range
of I/O connectivity, including 8 NMEA 0183 ports, 4 serial ports, 4
Gigabit Ethernet ports, as well as 6 USB 2.0 and 3 SuperSpeed USB
3.0 ports. The MC-7200-MP-T is designed to provide outstanding PC
performance, bringing a new level of flexibility and control to marine
applications.
Designed with the highest quality and durability in mind, the
marine-grade MC-7200-MP-T computer features a rugged chassis
that can withstand vibrations up to 1G to provide the most reliable
operation for harsh environments and conditions. In addition, low
power consumption delivers an optimal thermal solution and makes
installation easy for bridge systems in marine applications. Another
plus are the 1 PCIe (x16) slot and 2 universal PCI slots that allow users
to easily install a variety of adapters, including radar cards, PROFIBUS
cards, and VGA graphics cards, to fully satisfy all your marine network
needs.
Users can easily install Windows XP Embedded, XP Professional, or
Windows 7, to provide a flexible and friendly environment for system
development and application implementation.
Front View
LPT Port
(Dongle)
USB 2.0 x 2
(type A)
Power Button
System LEDs
(Power, Storage)
Power ON/OFF
Switch
Removable Storage Tray
Overview
Appearance
x86 fan less, wide temperature industrial computer with 3rd
Generation Intel
®
Core
™
processor
› High performance Intel® Core™ processor: i7 3555LE, i3
3120ME, or Celeron 1047UE
› Fanless design
› Full marine I/O design
› PCI/PCIe slot
› 3 independent displays (DVI-D x 2 + VGA x1 )
› 2 USB 3.0 ports, 6 USB 2.0 ports
› 2 SATA drive slots for greater storage capacity
› Dual power: 100 to 240 VAC and 24 VDC
› -40 to 70°C operating temperature range
Содержание
- Appearance 1
- Mc 7200 mp t 1
- Overview 1
- Processor 1
- X86 fan less wide temperature industrial computer with 3rd generation inte 1
- Computer 2
- Di x 8 do x 8 2
- Dimensions 2
- Display 2
- Dvi d vga output audio input output mic 2
- Ethernet interface 2
- Grounding screw 2
- Keyboard mouse 2
- Lan port x 4 rj45 2
- Marine displays and computers 2
- Nmea 0183 x 8 2
- Other peripherals 2
- Pcie x 1 x16 pci slot x 2 2
- Power input 100 240 vac 2
- Power input 24 vdc 2
- Rear view 2
- Serial port x 4 db9 2
- Specifications 2
- Usb 2 x 4 type a 2
- Usb 3 x 2 type a 2
- Available models 3
- Digital input 3
- Environmental limits 3
- Marine displays and computers 3
- Nmea interface 3
- Optional accessories can be purchased separately for ac power input 3
- Ordering information 3
- Package checklist 3
- Physical characteristics 3
- Power requirements 3
- Relay output 3
- Reliability 3
- Serial communication parameters 3
- Serial interface 3
- Serial signals 3
- Standards and certifications 3
- Warranty 3
