Moxa MC-7270-MP-T [3/3] Ordering information

Marine Displays and Computers

3

© Moxa Inc. All rights reserved. Updated Dec. 4, 2015. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.

Available Models

MC-7270-MP-T: x86-based industrial computer with 3rd gen. Intel® Core™ i7 3555LE

processor, 4 serial ports, 8 NMEA 0183 ports, 4 Gigabit Ethernet ports, 8 DIs, 8 DOs, 6 USB

2.0 ports, 2 USB 3.0 ports, 2 PCI slots, 1 PCIe x16 slot, VGA/DVI, and AC/DC power inputs

MC-7230-MP-T: x86-based industrial computer with 3rd gen. Intel® Core™ i3 3120ME

processor, 4 serial ports, 8 NMEA 0183 ports, 4 Gigabit Ethernet ports, 8 DIs, 8 DOs, 6 USB

PWC-C13EU-3B-183: Power cord with 3-pin connector, Euro plug

PWC-C13UK-3B-183: Power cord with 3-pin connector, British plug

PWC-C13AU-3B-183: Power cord with 3-pin connector, Australia plug

PWC-C13CN-3B-183: Power cord with 3-pin connector, China plug

Serial Interface

Serial Standards:

• 2 RS-232/422/485 ports, software-selectable (DB9 male)

• 2 RS-232 ports (DB9)

• 8 NMEA 0183 terminals (NMEA 2000 available on request)

Serial Communication Parameters

Serial Signals

RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND

RS-422: TxD+, TxD-, RxD+, RxD-, GND

RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND

RS-485-2w: Data+, Data-, GND

NMEA Interface

Serial Standards: NMEA 0183v2 (NMEA 2000 available on request)

Base Serial Standard:

• NMEA 0183: RS-422

• NMEA 2000: CAN bus (available on request)

Handshake: None

Digital Input

Input Channels: 8 dry channels, with 4 grounds

Digital Input Levels for Dry Contacts:

• Logic level 0: Close to GND

• Logic level 1: Open

Connector Type: 6-pin Phoenix-compatible 3.81 mm screw terminal

block x 2

Isolation: ESD protection to DNV specifications

Relay Output

Electrical Endurance: 100,000 operations

Contact Resistance: Max. 50 Mohm @ 6 V, 0.1 A

Connector Type: 8-pin Phoenix-compatible 3.81 mm screw terminal

blocks x 2

Isolation: Relay isolation; ESD protection to DNV specifications

LEDs

System: Storage, Power

LAN: 100M/Link x 4, 1000M/Link x 4 (on connector)

Physical Characteristics

Housing: Aluminum, sheet metal

Storage Temperature: -50 to 80°C (-58 to 176°F)

Ambient Relative Humidity: 5 to 95% (non-condensing)

Anti-Vibration:

• 0.7 g @ DNV 2.4 (Class A), sine wave, 2-100 Hz, 1 Oct./min., 1.5 hr

per axis

• 1 g @ DNV 2.4, random wave, 3-100 Hz, 2.5 hr per axis

• 2.1 g @ DNV 2.4 (Class C), sine wave, 2-50 Hz, 1 Oct./min., 1.5 hr

per axis

Power Requirements

Input Voltage:

FCC Part 15 Subpart B Class A

Marine Standards: IEC 60945 4th, IEC 61162

Marine Type Approval: DNV 2.4 and EU MR

Green Product: RoHS, cRoHS, WEEE

Reliability

Automatic Reboot Trigger: Built-in watchdog timer (WDT),

configurable for resets following 1-255 second hang intervals;

software programmable

Warranty

Warranty Period: 3 years

Package Checklist

• 2 6-pin digital input terminal blocks

• 2 8-pin digital output terminal blocks

• 8 5-pin terminal blocks for NMEA 0183 ports

• Documentation and driver CD

• Quick installation guide

Ordering Information
