MPC-2150 Hardware Hardware Connection Description
3-5
Wiring Requirements
This section describes how to connect peripheral devices to the panel computer.
You should read and follow these common safety precautions before proceeding with the installation of any
electronic device:
• Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must
cross, make sure the wires are perpendicular at the intersection point.
NOTE
Do not run signal or communication wiring together with power wiring in the same wire conduit. To avoid
interference, wires with different signal characteristics should be routed separately.
• Use the type of signal transmitted through a wire to determine which wires should be kept separate. The
rule of thumb is that wiring that shares similar electrical characteristics can be bundled together.
• Keep input wiring and output wiring separate.
• It is advisable to label the wiring to all devices in the system.
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing and/or wiring your
MPC-2150 Series.
Wiring Caution!
Calculate the maximum possible current in each power wire and common wire. Observe al
l electrical codes
dictating the maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your
equipment.
Temperature Requirements
Be careful when handling the unit. When the unit is plugged in, the internal components generate heat, and
consequently the outer casing may feel hot to the touch.
We recommend taking the following precautions to minimize heat build-up within the display:
• Position the display within ±40° of the vertical.
• Install an external fan to increase airflow upwards through the display if (a) the display is not positioned
within ±40° of the vertical, (b) the ambient temperature exceeds 25°C, or (c) the display is used in a
location with minimal ventilation.
Grounding the MPC-2150 Series
Before you power on the MPC-2150 Series, please ground the MPC-2150 as grounding and wire routing help
limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground
screw to the grounding surface prior to connecting the power.
ATTENTION
This product is intended
to be mounted to a well-grounded mounting surface, such as a metal panel.
Grounding: See the figure shown below for the location of the grounding connector. Connect the grounding
wire to an appropriate grounded metal surface.
