Marine Displays and Computers
2
www.moxa.com
Specifications
Computer
CPU:
Intel® Core™ i7-3517UE 1.7 GHz, or
Intel® Celeron® 1047UE 1.4 GHz
Supported OS: Windows Embedded Standard 7 32/64-bit, Windows 7
Professional 32/64-bit (the OS is not pre-installed)
System Chipset: Intel® HM65 Express Chipset
System Memory: 4 GB pre-installed (SDRAM)
USB: USB 2.0 hosts x 4, type A connectors, supporting system boot
up
Storage: 1 2.5” HDD/SSD slot + 1 CFast slot (storage is not pre-
installed)
BIOS: 64 Mbit Flash BIOS SPI type, ACPI function supported
Video Output: DVI-D x 1, VGA x 1 (female)
Buzzer: 75 to 85 db (IEC 60945 compliant)
Other Peripherals
Audio: Line-in and line-out interface, with 3.5 mm mini jack
KB/MS: 2 PS/2 interfaces supporting standard PS/2 keyboard and
mouse
Display
Panel Size: 15-inch viewable image size
Panel Type: TN
Touch: Capacitive multi-touch with glove-friendly support (touch
models only)
Aspect Ratio: 5:4
Pixels: 1024 x 768
Pixel Pitch (RGB): 0.297 (H) x 0.297 (V) mm
Response Time: 20 ms (gray to gray)
Contrast Ratio: 700:1
Light Intensity: 1000 cd/m2
Active Display Area: 304.128 (H) x 228.096 (V) mm
Ethernet Interface
LAN: 2 auto-sensing 10/100/1000 Mbps ports (RJ45 port)
Magnetic Isolation Protection: 1.5 kV built-in
Serial Interface
Serial Standards: 2 RS-232/422/485 ports, software-selectable (DB9
male)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF
Baudrate: 50 bps to 115.2 Kbps (supports non-standard baudrates;
see user’s manual for details)
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
LEDs
System: Storage, Power
LAN: 100M/Link x 2, 1000M/Link x 2 (on connector)
Front Panel
LEDs: MENU, Brightness, INFO, Brightness Mode, Day/Dusk/Night,
Storage
Smart OSD: Yes
Physical Characteristics
Housing: Aluminum sheet metal
Weight: 6.5 kg
Dimensions: 356 x 315 x 77.2 mm (14.02 x 12.40 x 3.04 in)
Mounting: Panel and VESA mounting (mounting kit is optional)
System Cooling: Fanless thermal design
Environmental Limits
Operating Temperature: -40 to 70°C (-40 to 158°F)
Storage Temperature: -40 to 70°C (-40 to 158°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-Vibration: 2 g rms, 5-500 Hz frequency, compliant with IEC
60068-2-6 standard
Anti-shock: 20 g rms, half sine wave under system operating, 11 ms
duration, compliant with IEC 60068-2-27 standard
Power Requirements
Input Voltage:
• DC: 12/24 VDC (Range 9 to 36 VDC)
• AC: 100 to 240 VAC
Power Consumption: Less than 120 W, 2.5 A @ 24 VDC
Standards and Certifications
Safety: UL 60950-1, IEC 60950-1
EMC: EN 55022/24
EMI: CISPR 22, FCC Part 15B Class A
EMS:
• IEC 61000-4-2 ESD: Contact 4 kV; Air 8 kV
• IEC 61000-4-3 RS: 10 V/m (80 MHz to 1 GHz)
• IEC 61000-4-4 EFT: Power 2 kV; Signal 1 kV
• IEC 61000-4-5 Surge: Power 2 kV; Signal 1 kV
• IEC 61000-4-6 CS: 10 V
• IEC 61000-4-8, IEC 61000-4-11
Ingress Protection Rating: IP66 (front) / IP22 (rear) / NEMA 4X
Green Product: RoHS, cRoHS, WEEE
Warranty
Warranty Period:
• Computer system: 3 years
• LCD panel: 1 year
Details: See www.moxa.com/warranty
