Moxa MPC-2157X-T [3/3] Ordering information

Marine Displays and Computers

3

© Moxa Inc. All rights reserved. Updated Nov. 3, 2015. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.

Ordering Information

Dimensions

Unit: mm (inch)

Available Models

MPC-2150X: 15-inch fanless panel computer with Intel® Celeron® 1047UE 1.4 GHz processor,

RS-232/422/485 serial ports, Gigabit LAN ports, USB 2.0 ports, -40 to 70°C operating

RS-232/422/485 serial ports, Gigabit LAN ports, USB 2.0 ports, -40 to 70°C operating temperature, 2.5” SSD tray and CFast slot, dual AC/DC power

inputs, tape bonding

MPC-2157Z: 15-inch fanless panel computer with Intel® Core™ i7 3517UE 1.7 GHz processor, RS-232/422/485 serial ports, Gigabit LAN ports, USB

2.0 ports, -40 to 70°C operating temperature, 2.5” SSD tray and CFast slot, dual AC/DC power inputs, tape bonding, projected capacitive touch screen

Optional Mounting Kits (can be purchased separately)

MPC-MD-2-15-PMTK: 8 screws for panel mount

MPC-MD-2-15-VESAMTK: VESA mounting bracket, 100 x 100 mm and 75 x 75 mm

Package Checklist

• 1 MPC-2150 panel computer

• 1 2-pin terminal block for DC power input

• 2.5” SATA SSD/HDD installation kit

75 (2.95)

337 (13.27)

321.1 (12.64)

339 (13.35)

Panel Cutout Dimension

65.5
