MPC-2190 Hardware Display Control Interface Commands
B-5
AD? (Query AC Input Power Detect Function Status)
If the MPC-2190 supports AC power input, users can use command is to query AC Input Power Detect Function
Status.
0x00 AC Input Power Detect is OFF
0xFF AC Input Power Detect is ON
Example：
Send AD? command to Query AC Input Power Detect Function Status
0x07 0xFF 0x41 0x44 0x3F 0x00 0x35
ACK
0x06 0xFF 0x41 0x44 0x3F 0x01 0x35 0x00 0xFF
BLI (Brightness Control)
This command is to set the panel brightness. Brightness range is from 0x00 to 0xFF. Default Brightness is 160.
LEN=one date byte.
Example：
Set brightness to 255(0xFF)
0x07 0xFF 0x42 0x4C 0x49 0x01 0x21 0xFF 0x00
ACK
0x06 0xFF 0x42 0x4C 0x49 0x01 0x22 0xFF 0x00
Query current brightness value
0x07 0xFF 0x42 0x4C 0x49 0x00 0x22
ACK
0x06 0xFF 0x42 0x4C 0x49 0x01 0x22 0xFF 0x00
DUF (Disable UART Command Function)
Users can use this command to disable related command control. LEN=one date byte.
DATA IDCHK Function description
0x00 0xFF Disable all command control
0x01 0xFE Disable BRI control
0x02 0xFD Disable BRL control
0x04 0xFB Disable BRM control
0x08 0xF7 Disable BZZ control
0x10 0xEF Disable ETC control
0x20 0xDF Disable GMB control
0x40 0xBF Disable POT control
Example：
Disable all command control
0x07 0xFF 0x44 0x55 0x46 0x01 0x19 0x00 0xFF
ACK
0x06 0xFF 0x44 0x55 0x46 0x01 0x1A 0x00 0xFF
NACK
0x15 0xFF 0x44 0x55 0x46 0x01 0x0B 0x00 0xFF
EMS (ECDIS Mode Select)
For the ECDIS models, users can use this command to switch DAY, DUSK and NIGHT mode. LEN=one date
byte.
DATA IDCHK
