Moxa MPC-2260X Технические характеристики онлайн
Marine Displays and Computers
1
www.moxa.com
MPC-2260 Series
Introduction
26-inch ECDIS color calibrated, fanless panel computers
MPC-2260 series panel computers feature an Intel 3rd generation
processor and 4 GB of system memory to deliver a reliable, high
performance platform of wide versatility for use in industrial marine
environments. With its RS-232/422/485 serial, NMEA 0183, and
Gigabit Ethernet LAN ports, the MPC-2260 series panel computer
supports a wide variety of serial and marine-specific interfaces as well
as high speed IT communications, all with native network redundancy.
The MPC-2260 series comes with a range of standard display
enhancements useful in industrial environments (including 0 to 100%
full range dimming, 178°/178° wide viewing angles, and optional
optical bonding), as well as Moxa’s innovative SavvyTouch display
controls.
The MPC-2260 series of panel computers are compliant with several
industrial marine standards, including IEC 60945 4
th
, IEC 61174,
IEC 61162, DNV2.4, and IACS E10, verifying their resilient durability
in marine operations. An optional IP65-rated unibody shell provides
strong additional protection against the harsh conditions found
in marine environments. The MPC-2260 delivers a rugged, type
approved, high performance and user-friendly panel computer perfect
for ECDIS navigation systems and other marine IBS applications.
Appearance
DC Power
Input
USB 2.0
Host x 4
RS-232/422/485 Port x 2
DVI-D/VGA
Output
NMEA 0183 Port x 8
Gigabit LAN Port x 2
PS/2 Mouse/
Keyboard
Line in/out
2.5” SSD Tray x 2
SavvyTouch Display
Control Button x 5
Panel
Grounding Connector
AC Power Input
Buzzer
› 26-inch panel computer
› Color calibrated for ECDIS compliance
› Fanless design
› SavvyTouch display controls
› 3rd Generation Intel® Core™ or Celeron® processor (Default:
Celeron® 1047UE, 1.40 GHz with Intel® HD Graphics)
› Built-in NMEA 0183 and software selectable RS-232/422/485
interfaces
› Multi-power supplies (AC & DC)
Содержание
- Appearance 1
- Inch ecdis color calibrated fanless panel computers 1
- Introduction 1
- Mpc 2260 series 1
- Computer 2
- Display 2
- Environmental limits 2
- Ethernet interface 2
- Front panel 2
- Marine displays and computers 2
- Nmea interface 2
- Other peripherals 2
- Physical characteristics 2
- Power requirements 2
- Reliability 2
- Serial communication parameters 2
- Serial interface 2
- Serial signals 2
- Specifications 2
- Standards and certifications 2
- Warranty 2
- Available models 3
- Dimensions 3
- Important safety precaution 3
- Marine displays and computers 3
- Optional accessories can be purchased separately for ac power input 3
- Optional mounting bracket kits can be purchased separately 3
- Ordering information 3
- Package checklist 3
