www.moxa.com
Marine Displays and Computers
MD-124 Series
24-inch wide screen marine display, 16:9 aspect ratio,
full HD 1920 x 1080 pixel resolution
MD-124 marine displays are designed to meet the great requirements
of industrial-grade maritime service. The 24 inch screen has a 16:9
aspect ratio and 1920 x 1080 pixel resolution, and features PIP
(Picture-In-Picture) and PBP (Picture-By-Picture) functions to allow
a variety of display configurations. With full range dimming, optical
bonding (Y models only), and wide angle views, the MD-124 is ideal
not only for ECDIS displays, but for any other bridge application, as
well. Finally, the MD-124 also comes with both AC and DC power
inputs, making it ready for installation on any ship’s bridge.
MD-124 displays are fully compliant with many a variety of industrial
marine standards, including IEC 60945, DNV, and IACS-E10, amply
demonstrating their suitability for on-board marine uses.
Menu
M
OSD Control Buttons
AC Power
Input/Output
DC Power
Input
USB
(Z model only)
RS-232/422/485
Port x 2 (1 reserved)
Buzzer
Connector
Ground
Connector
BNC
Composite x 3
VGA Output
DVI-I Input x 2
Overview
Appearance
› 24-inch wide viewable image size with 16:9 aspect ratio and
1920 x 1080 pixel resolution
› LED backlighting
› Optical bonding (Y model)
› Surface capacity touch (Z model)
› ECDIS color calibration model available (by request)
› PIP/PBP
› Multi-power input (24 VDC, 110 to 230 VAC)
› IP66 rated front panel
