Marine Displays and Computers
2
www.moxa.com
Specifications
Computer
CPU: lntel Celeron® Processor 1047UE (2M Cache, 1.40GHz)
OS: Windows 7 Professional, Windows XP Embedded, Windows
Embedded Standard 7, Windows XP SP3
System Chipset: Intel HM65
System Memory: 8 GB capacity, 4 GB pre-installed: 1 slot of 4 GB
DDR3-1600 204 pin SO-DIMM SDRAM
USB: 4 bootable USB 2.0 hosts, type A connectors
Storage: 2 SATA III interfaces: 6 Gbps, 2.5” removable storage trays
BIOS: 64 Mbit Flash BIOS with SPI, ACPI
Graphics Controller: Intel HM65 Express chipset built in
Video Outputs: DVI-D x 1, VGA x 1 (female)
Other Peripherals
Audio: line in/out, 3.5 mm mini jack
KB/MS: 2 PS/2 interfaces supporting standard PS/2 keyboard and
mouse
Display
Panel Size: 26” viewable image size
Panel Type: MVA
Aspect Ratio: 16:10
Pixels: 1920 x 1200 (WUXGA)
Pixel Pitch (RGB): 0.2865 (H) x 0.2865 (V) mm
Response Time: 15 ms (gray to gray)
Contrast Ratio: 1500:1
Light Intensity: 300 cd/m^2
Viewing Angles: 176˚/176˚
Active Display Area: 550.08 (H) x 343.8 (V) mm
Max Colors: 16.7M (8 bit color)
Resolution:
• VGA: 640 x 480
• SVGA: 800 x 600
• XGA: 1024 x 768
• SXGA: 1280 x 1024
• WSXGA+: 1920 x 1080
• WUXGA: 1920 x 1200
Ethernet Interface
LAN: 2 auto-sensing 10/100/1000 Mbps ports (RJ45)
Magnetic Isolation Protection: 1.5 kV built in
Serial Interface
Serial Standards: 2 RS-232/422/485 ports, software-selectable (DB9
male)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 115.2 Kbps (supports non-standard baudrates;
see user’s manual for details)
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
NMEA Interface
Serial Standards: 8 NMEA 0183 ports
Base Serial Standard: RS-422
Optical Isolation Protection: ±6 kV contact discharge, ±8 kV air
discharge
Voltage Differential: -15 V to +15 V
Baudrate: 4800 bps
Data Bits: 8
Stop Bits: 1, 1.5, 2
Parity: None
Handshake: None
LEDs
System: Storage, Power
LAN: 100M/Link x 2, 1000M/Link x 2 (on connector)
Front Panel
LEDs: Storage
SavvyTouch Display Control Buttons: ECDIS, INFO, Brightness (+, -),
MENU
Physical Characteristics
Housing: Aluminum sheet metal
Weight: 16.6 kg
Dimensions: 621 x 444 x 90 mm (24.45 x 17.48 x 3.57 in)
Mounting: VESA, panel, and desktop mounting
Environmental Limits
Operating Temperature: -15 to 55°C (5 to 131°F)
Storage Temperature: -20 to 60°C (-4 to 140°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Note: If you expect the storage temperature to exceed 40°C, please ensure that
the ambient relative humidity remains below 60%.
IP Rating:
• Front: IP54
• Rear: IP22
Anti-Vibration:
• 0.7 g @ DNV2.4 (Class A), sine wave, 2-100 Hz, 1 Oct./min., 1.5 hr
per axis
• 1 g @ DNV2.4, random wave, 3-100 Hz, 2.5 hr per axis
• 2.1 g @ DNV2.4 (Class C), sine wave, 2-50 Hz, 1 Oct./min., 1.5 hr per
axis
Power Requirements
Input Voltage:
• 24 VDC, 6 A or (18 to 34 VDC, 8 A max.), screw-type terminal block
• 100 to 240 VAC, 50 to 60 Hz, 2 A, AC power inlet
Standards and Certifications
Safety: UL 60950-1, EN 60950-1, IEC 60950-1
EMC: EN 55022/24, CISPR 22, FCC Part 15B Class A
Marine: IEC 60945 4th, IEC 61174, IEC 61162, DNV2.4, IACS E10
Green Product: RoHS, cRoHS, WEEE
Reliability
Automatic Reboot Trigger: Built-in WDT (watchdog timer) supporting
1-255 levels for time interval system reset, software programmable
Warranty
Warranty Period:
3 years for computer systems,
1 year for LCD panels
Details: See www.moxa.com/warranty
