USB Host

The optional USB port on the bottom of the MD-119 is used to

connect the touch-screen interface to a peripheral device server.

Connect the MD-119 USB port to a touch-screen device server via

a standard USB cable. Drivers for the touch screen interface are

provided on the MD-119 software CD.

BNC Composite Connectors

The MD-119 offers three BNC composite connectors for

audio/video interfaces.

Buzzer Terminal

The bottom panel of the MD-119 is equipped with a terminal block

for powering the buzzer. Install the leads of a 5 to 12 V power

source into the terminal block marked BUZZER to enable the

buzzer feature.

7. Powering on the MD-119

To power on the MD-119, connect the “terminal block to power

jack converter” to the MD-119’s DC terminal block (located on the

side panel), and then connect the power adaptor. For the AC input,

simply connect the power cord to the power source. It takes about

5 seconds for the system to boot up. Once the system is ready, the

Power LED on the front panel will light up. To enable the power

failover function, connect both AC and DC power inputs.
