BNC Composite Connectors

The MD-124 offers three BNC composite connectors for

audio/video interfaces.

Buzzer Terminal

The bottom panel of the MD-124 is equipped with a terminal block

for powering the buzzer. Install the leads of a 5 to 12 V power

source into the terminal block marked BUZZER to enable the

buzzer feature.

7. Powering on the MD-124

To power on the MD-124, connect the “terminal block to power

jack converter” to the MD-124’s DC terminal block (located on the

side panel), and then connect the power adaptor. For the AC input,

simply connect the power cord to the power source. It takes about

5 seconds for the system to boot up. Once the system is ready, the

Power LED on the front panel will light up.
