Moxa W321-LX Технические характеристики онлайн
1
www.moxa.com
info@moxa.com
Wireless Computers
RISC platform embedded Linux computers with WLAN, LAN,
and 2 or 4 serial ports
The W321/341 series of embedded Linux computers come in two
models with either 2 or 4 software selectable RS-232/422/485 ports.
These compact RISC platform computers feature Wi-Fi and an RJ45
Ethernet port. USB 2.0 hosts and SD sockets (for storage expansion)
are available on some models. The W321/341 series’ Linux OS runs
on Moxa’s own ART 32-bit ARM9 processor, providing a powerful
and reliable platform for harsh industrial environments. You will find
these compact compputers ideal for a variety of machine-to-machine
applications, including data acquisition, protocol conversion, and
remote device control and monitoring.
W321/341 Series
W321
W341
Appearance
Overview
› MOXA ART ARM9 32-bit 192 MHz processor running Linux 2.6.38
kernel
› 32 or 64 MB RAM, and 16 MB flash disk on board
› 802.11b/g/n WLAN with repeater function
› WEP, WPA, and WPA2 encryption
› 10/100 Mbps Ethernet for network redundancy
› Relay output for external alarm connection (W341 only)
› 4 DIs, 4 DOs (W321 only)
› SD socket for storage expansion
› Mountable on walls or DIN rails
› Designed to withstand continuous 5 g vibration and 50 g shocks
› Robust, fanless design
W321 W341
Ethernet
(10/100BaseTx)
12 to 48 VDC
Wireless LAN
Antenna
Internal SD Slot for
Storage Expansion
(remove cover to access)
Serial Port 2
(RS-232/422/485)
(RS-232/422/485)
Serial
Console Port
4 DIs, 4 DOs
Reset Button
Wireless LAN
Antenna
Serial
Console Port
Ethernet
(10/100BaseTx)
12 to 48 VDC
Internal SD Slot for
Storage Expansion
(remove cover to access)
Serial Port 1 to 4
(RS-232/422/485)
Relay Output
USB 2.0 Host x 2
Reset Button
