W321/341 Linux Managing Embedded Linux
3-5
Loading Factory Defaults
You can press the reset-to-default button over 5 seconds. The system will load the factory setting. And
will destroy all on /home & /etc & /usr/local/bin & /usr/local/sbin & /usr/local/lib & /usr/local/libexec &
/tmp directory files. The first 5 seconds the ready-light will be toggled for each one second. If you
continue to press over 5 second, the read-light will be off and load the factory defaults.
Enabling and Disabling Daemons
The following daemons are enabled when the W321/341 unit boots up for the first time.
snmpd ………….
SNMP Agent daemon
inetd …………….
Internet Daemons
ftpd ……………….
FTP Server / Client daemon
sshd ………………
Secure Shell Server daemon
Type the command ps to list all processes currently running.
192.168.3.127 - PuTTY
PID USER VSZ STAT COMMAND
1 root 1872 S init [3]
2 root 0 SW [kthreadd]
3 root 0 SW [ksoftirqd/0]
4 root 0 SW [kworker/0:0]
5 root 0 SW [kworker/u:0]
6 root 0 SW [rcu_kthread]
7 root 0 SW< [khelper]
8 root 0 SW [sync_supers]
9 root 0 SW [bdi-default]
10 root 0 SW< [kblockd]
11 root 0 SW [khubd]
12 root 0 SW< [rpciod]
13 root 0 SW [kswapd0]
14 root 0 SW [kworker/0:1]
15 root 0 SW [fsnotify_mark]
16 root 0 SW< [aio]
17 root 0 SW< [nfsiod]
18 root 0 SW< [crypto]
25 root 0 SW [mtdblock0]
26 root 0 SW [mtdblock1]
27 root 0 SW [mtdblock2]
28 root 0 SW [mtdblock3]
29 root 0 SW< [wusbd]
30 root 0 SW [kworker/u:1]
31 root 0 SW [mmcqd/0]
58 root 0 SWN [jffs2_gcd_mtd3]
71 root 0 SW [kjournald]
92 root 0 SW [RtmpTimerTask]
93 root 0 SW [RtmpMlmeTask]
94 root 0 SW [RtmpCmdQTask]
102 root 1940 S /bin/inetd
106 bin 1856 S /bin/portmap
111 root 2932 S /bin/sh --login
116 root 1924 S /bin/snmpd
