The following table lists the input signal-level jumper assignment for
each input channel:
Audio Channel Jumper
IN1 JP1
IN2 JP2
IN3 JP3
IN4 JP4
Software Installation
The DMAN 2044 software includes a Windows 98/95 driver and various
control utilities. The DMAN 2044 driver software interfaces with
Windows audio applications, as well as to the Windows audio mixer
application. The DMAN 2044 Windows 98/95 Driver/Installation
Diskette titled “DMAN 2044 Drivers, PC Format” contains all of the soft-
ware necessary to configure, control, and operate the DMAN 2044 audio
card.
Windows 95 Driver & Utility Installation
In order for you to use the DMAN 2044 with your Windows 95 applica-
tions, you will be required to first load the DMAN 2044 Windows 95 soft-
ware drivers. Follow the steps below for a no-hassle installation:
1. After physical installation of the DMAN 2044 card, boot your com-
puter system and start Windows 95.
2. As the computer enters Windows 95, it will automatically detect the
DMAN 2044 board’s presence in your computer. You will see a dia-
log box similar to the one pictured below:
Windows 95 Detects New Hardware
