4. Options four through seven connect the hardware TDIF inputs 1 & 2, 3

& 4, 5 & 6, or 7 & 8 (respectively) directly to the card’s hardware TDIF

outputs 3 & 4. For example, if "H/W In 1/2" were selected, any signal

present at the IN1 port will be copied to OUT3, and any signal present

at the IN2 port will be copied to OUT4. This same behavior applies to

"H/W In 3/4", "H/W In 5/6", and "H/W In 7/8" when selected.

The rightmost vertical column of Patchbay/Router page, "H/W Out

SP/ANA," connects the Delta TDIF’s hardware Analog and S/PDIF

outputs simultaneously to one of eight sources:

1. The default setting, "WavOut SP/ANA", connects the Analog Outs

and the S/PDIF Out port to your music software or

Windows/Macintosh multimedia applet. In other words, when

music software plays audio to the device named "WavOut SP/ANA

Delta-TDIF" it will be routed directly to the hardware Analog and

S/PDIF outputs on your Delta TDIF PCI host card’s breakout cable.

2. The second option, "Monitor Mixer", connects the Analog and S/PDIF

Out ports to the outputs of the Delta TDIF monitor mixer. For more

information on the capabilities of the monitor mixer, please see the

section "Monitor Mixer Page".

3. The third option, "SP/ANA In", connects the Analog and S/PDIF Out

ports directly to either the hardware Analog input or the hardware

S/PDIF input on the Delta TDIF’s breakout cable. This selection,

Analog or S/PDIF, is made in the control panel’s Hardware Settings

page (see section, “Hardware Settings Page”). The left channel of the

selection (Analog In or S/PDIF In) is routed to the left channel of

Analog Outs and S/PDIF Out and the right channel of the selection

(Analog or S/PDIF In) is routed to the right channel of Analog Outs

and S/PDIF Out.

4. The fourth option, "SP/ANA In (L/R Rev.)", functions identically to

the third option, except that the left and right channels are swapped.

Therefore in this mode, the left channel of the selected input (Analog

In or S/PDIF In) is routed to the right channel of Analog Outs and the

S/PDIF Out, and the right channel of the selected input is routed to

the left channel of Analog Outs and the S/PDIF Out.

5. Selections five through eight connect the hardware TDIF inputs 1 & 2,

3 & 4, 5 & 6, or 7 & 8 (respectively) directly to the card’s Analog and

S/PDIF Out ports. For example, if "H/W In 1/2" were selected, any

signal present at the IN1 port will be sent to the left channel of the

Analog Outs and S/PDIF Out, and any signal present at the IN2 port

will be sent to the right channel of the Analog Outs and S/PDIF Out.

This same behavior applies to "H/W In 3/4", "H/W In 5/6", and

"H/W In 7/8" when selected.
