P/N: 1802015000011
ioLogik E1500 Series
Quick Installation Guide
Second Edition, August 2012
Overview
With a threaded M12 Ethernet port to ensure wired connectivity, a
spring-type terminal block for vibration-resistant cabling, and a
DIN rail mount assembly, the ioLogik E1500 series is designed to
withstand the severe vibrations experienced with rolling stock and
wayside applications. Carefully engineered channel-to-channel
isolation gives protection against cross-line power surges and
crosstalk, ensuring stable data communications. In addition, the
ioLogik E1500 is compliant with EN 50121-3-2, EN 50121-4, and
essential sections of the EN 50155 standard (covering operating
temperature, power input voltage, electrical surges, ESD, and
vibration), all of which are required for electronic equipment used
on or around railway vehicles.
Model Selection
ioLogik
DI
DO
DIO
Relay
AI
AO
RTD
TC
E1510-T
12
–
–
–
–
–
–
–
E1512-T
4
–
4
–
–
–
–
–
Package Checklist
• 1 ioLogik E1500 series remote I/O product
• Documentation and software CD
• Quick installation guide (printed)
Specifications
System
10/100 Mbps, M12 connector
1.5 KV magnetic isolation
Modbus/TCP, TCP/IP, UDP, DHCP, Bootp,
HTTP
24 VDC nominal, 12 to 48 VDC
I/O cable, max. 14 AWG
144 x 124 x 30 mm (5.67 x 4.88 x 1.18 in)
825 g
-40 to 85°C (-40 to 185°F)
-40 to 85°C (-40 to 185°F)
Ambient Relative
5 to 95% (non-condensing)
Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to
function properly at higher altitudes.
Standards and
UL 508, EN 50155, EN 50121-3-2, EN
50121-4
5 years
See www.moxa.com/warranty
Digital Input
NPN, PNP, and Dry contact
DI or Event Counter
• On: short to GND
• Off: open
Wet Contact • On: 0 to 3 VDC
• Off: 10 to 30 VDC
3k VDC or 2k Vrms
250 Hz, power off storage
Digital Output
DO or Pulse Output
1 ms/500 Hz
Over-voltage
45 VDC
2.6 A (4 channels @ 650 mA)
175°C (typical), 150°C (min.)
200 mA per channel
3k VDC or 2k Vrms
Installation
Power and Networking
Connect the +12 to +48 VDC power line to the ioLogik E1500’s
terminal block V+ terminal, and connect the ground from the
power supply to the V- terminal. If an earth ground is available,
connect the ground pin ( ).
Mounting and Cabling
The ioLogik E1500 can be used with both DIN rail and wall mounts.
When mounting on a DIN rail, release the bottom mounting kit,
install the ioLogik on the rail, and then restore the bottom
mounting kit to fix the ioLogik to the rail. When using wall
mounting, release both the upper and bottom DIN rail kits.
The ioLogik E1500 has an M12 Ethernet port for connecting either
a standard direct-Ethernet or crossover-Ethernet cable via a
locking M12 connector.
LED Indicators
Type
Color
Description
PWR
Green
System power in ON
Off
System power is OFF
RDY
Green
System is ready
Green Blinking
Located
Red
System Booting-up Error
Green/Red
Blinking
Safe Mode
Red Blinking
Firmware upgrade (LED flashes for 3
seconds then stays red until restart)
Off
System is not ready
LAN
Green
100 Mbps
Amber
10 Mbps
Blinking
Data Transmitting
Off
Ethernet Off
EXP
Green
Expansion Mode Ready
Red
Configuration Failure
Off
Stand-alone Mode
DI
Green
Channel ON
Off
Channel OFF
DIO
Green
Channel ON
Off
Channel OFF
