digital audio signal. The default is "None" and rarely will any user want to set the

value to "50/15uSec" which indicates an S/PDIF emphasis mode.

Professional Format Advanced Settings (Data Type):

The user may assign the outgoing data as audio or non-audio data. Many devices

ignore this setting. The obvious default is "audio."

Professional Format Advanced Settings (Emphasis):

The user may choose to indicate or not indicate if pre-emphasis has been applied to

the outgoing digital audio signal. The default is "None" and rarely will any user

want to set the value to "CCITT" or "50/15uSec" which are the two types of empha-

sis available in the AES/EBU status block.

About Page

The "About" page, while displaying the handsome M Audio logo and applicable

sion. If you have internet browsing capabilities and are currently connected to the

internet, clicking on the Midiman copyright will link you to the M Audio / Midiman

web site.

Save, Delete, Load Buttons; H/W Installed

At the rightmost side of the Delta Control Panel are the Save, Load and Delete but-

tons as well as an "installed hardware" set of radio buttons.

SAVE, DELETE, LOAD: The Delta Control Panel will retain the last settings that

were entered, except for mixer channels with solo settings -- they will default back

to ‘on’, and not to solo or muted. However the Save, Delete, and Load functions will

allow you to store different sets of control panel settings under different configura-

tion file names. These configurations are then available for recall at a later date and

time.

Clicking the ‘Save’ button brings up a dialog box prompting you to name the current

configuration. Once you have done this, click ‘OK’, and your control panel settings

have been saved to disk. If you decide that you no longer need a particular config-

uration, click the ‘Delete’ button. Highlight the name of the configuration file that

you wish to delete, and click the ‘OK’ button. To recall a set of saved control panel

settings, click the ‘Load’ button. Highlight the name of the configuration file that

you wish to recall, and click ‘OK’. Those settings will now appear in the Delta

Control Panel and the driver will automatically update the hardware.

H/W INSTALLED: Several Delta cards may be installed in a system at one time

(note: this option may not exist in the first release of Delta software drivers). This

section displays all (a maximum of four) installed Delta cards, and allows you to

select which particular card is under the control of the control panel software. To
