Remote I/O
2
www.moxa.com
ioLogik R1214 Specifications
Inputs and Outputs
Digital Inputs: 6 channels
Relays: 6 channels
Isolation: 3k VDC or 2k Vrms
Digital Input
Sensor Type: Wet Contact (NPN or PNP), Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact (DI to COM):
• On: 10 to 30 VDC
• Off: 0 to 3 VDC
Common Type: 6 points per COM
Counter Frequency: 2.5 kHz
Digital Filtering Time Interval: Software Configurable
Relay
Type: Form A (N.O.) power relay
Contact Current Rating: Resistive load: 5 A @ 30 VDC, 250 VAC,
110 VAC
Breakdown Voltage: 500 VAC
Relay On/Off Time: 1500 ms (max.)
Initial Insulation Resistance: 1000 mega-ohms (min.) @ 500 VDC
Mechanical Endurance: 5,000,000 operations
Electrical Endurance: 100,000 operations @ 5 A resistive load
Contact Resistance: 100 milli-ohms (max.)
Pulse Output: 0.3 Hz at rated load
Note: Ambient humidity must be non-condensing and remain between 5 and
95%. The relays of the ioLogik R1214 may malfunction when operating in high
condensation environments below 0°C.
Power Requirements
Input Voltage: 12 to 48 VDC
Input Current: 207 mA @ 24 VDC
ioLogik R1241 Specifications
Inputs and Outputs
Analog Outputs: 4 channels
Isolation: 3k VDC or 2k Vrms
Analog Output
Resolution: 12 bits
Output Range: 0 to 10 VDC, 0 to 20 mA, 4 to 20 mA
Voltage Output: 10 mA (max.)
Accuracy:
±0.1% FSR @ 25°C
±0.3% FSR @ -40 and 75°C
Load Resistor: Internal register: 400 ohms
Note: 24 V of external power required when loading exceeds 1000 ohms.
Power Requirements
Input Voltage: 12 to 48 VDC
Input Current: 343 ma @ 24 VDC
Inputs and Outputs
Analog Inputs: 8 channels
Isolation: 3k VDC or 2k Vrms
Analog Input
Type: Differential input
Resolution: 16 bits
I/O Mode: Voltage / Current (jumper selectable)
Input Range: 0 to 10 VDC, 0 to 20 mA, 4 to 20 mA, 4 to 20 mA
(burn-out mode)
Accuracy:
±0.1% FSR @ 25°C
±0.3% FSR @ -10 and 60°C
±0.5% FSR @ -40 and 75°C
ioLogik R1240 Specifications
Sampling Rate:
• All channels: 12 samples/sec
• Per channel: 1.5 samples/sec
• Only one channel enabled: 12 samples/sec
Input Impedance: 10 mega-ohms (min.)
Built-in Resistor for Current Input: 120 ohms
Power Requirements
Input Voltage: 12 to 48 VDC
Input Current: 216 mA @ 24 VDC
Wet Contact (DI to COM):
• On: 10 to 30 VDC
• Off: 0 to 3 VDC
Common Type: 8 points per COM
Counter Frequency: 2.5 kHz
Digital Filtering Time Interval: Software Configurable
Digital Output
Type: Sink
I/O Mode: DO or Pulse Output
Pulse Output Frequency: 5 kHz
Over-Voltage Protection: 45 VDC
Over-Current Protection: 2.6 A (4 channels @ 650 mA)
Over-Temperature Shutdown: 175°C (typical), 150°C (min.)
Current Rating: 200 mA per channel
Power Requirements
Input Voltage: 12 to 48 VDC
Input Current: 187 mA @ 24 VDC
Common Specifications
Serial
Interface: 2 RS-485-2w terminal block ports
Serial Line Protection:
• ESD Protection: 15 kV
• Surge Protection: 1 kV
• High/Low Resistor for RS-485: 1 kΩ, 150 kΩ
Parity: None, Even, Odd
Data Bits: 8
Stop Bits: 1, 2
Baudrate: 1200 to 921600 bps
Protocols: Modbus RTU (slave)
Physical Characteristics
Wiring: I/O cable max. 16 AWG
Dimensions: 27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)
Weight: Under 200 g (0.44 lb)
Mounting: DIN-rail or wall
Environmental Limits
Operating Temperature:
Standard Models: -10 to 75°C (14 to 167°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
