Click&Go Plus Click&Go Plus™ Components

2-2

Timer

The Timer function allows users to delay an action, trigger an action to run, or repeat an action. A timer is

activated by a change of the logic event. After the timed interval has expired, the output will be performed.

The Timer can be used in the following circumstances:

• If Condition: Timeout

• THEN/ELSE Action: Start / Stop / Restart

NOTE

you use a THEN/ELSE action to Stop / Stop / Restart Timer, the “IF condition” should be an edge-

triggered

condition

. (For example, if you are using the DI as an if condition, then OFF to ON / ON to OFF / Change are

all

edge

-triggered conditions.)

Timer Settings

Name

The name that will be shown in Click&Go rules.

Time Interval

The duration of the timer.

Initial State

The initial state of the timer when the ioLogik 2500 starts up.

Add

For adding a new timer function.

Apply

For changing the setting of an existing timer function.
