Click&Go Plus Overview
1-2
Click&Go Plus™ Overview
Click&Go Plus™ logic can be managed and configured with the IOxpress utility to handle front-end events.
IOxpress’s graphical user interface also provides easy access to all status information and ioLogik 2500
settings.
Click&Go plus™ Features
Click&Go Plus Logic has the following key features:
• Easy local logic control using graphical and intuitive IF-Then-Else style constructions
• Up to 48 user-defined rules
• Choice of email, TCP, UDP, and SNMP trap for active I/O messaging
• Customizable message content with dynamic fields for time, date, IP address, and more
• Up to 10 simultaneous IP destinations for TCP/UDP messaging
• Internal register function for remote output control when Click&Go plus is running
• Timer Delay function for timing events
• Configurable interval for time-triggered events
Using Click&Go Plus™ Logic
The following flowchart shows an overview of the Click&Go Plus ™ Logic configuration process:
More information is available about each of these four topics:
• Setting up I/O Components: See the ioLogik 2500 User’s Manual.
• Creating C&G+ Components: See Chapter 2 of this manual.
• Designing C&G+ Logic Rules: See Chapter 3 of this manual.
• Running C&G+ Simulation: See Chapter 4 of this manual.
1. Set up
I/O Components
2. Create
C&G+ Components
3. Design
C&G+ Logic Rules
4. Run
C&G+ Simulation
