2
www.moxa.com
info@moxa.com
Programmable RTU Controllers
Ethernet Interface
LAN: 2 x 10/100 Mbps, 2 MACs (IPs), RJ45
Protection: 1.5 kV magnetic isolation
Serial Communication
Interface:
• 2 RS-232/422/485 ports, software selectable (DB9 male)
• 1 RS-232 debug port (4-pin connector)
Serial Line Protection: 15 kV ESD for all signals
Serial Communication Parameters
Parity: None, Even, Odd
Data Bits: 7, 8
Stop Bits: 1, 2
Flow Control: RTS/CTS, XON/XOFF
Baudrate: 300 bps to 921.6 kbps
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND, RI
RS-422: Tx+, Tx-, Rx+, Rx-, GND
RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND
RS-485-2w: Data+, Data-, GND
Inputs and Outputs
Analog Inputs: 8 channels
Digital Inputs: 8 channels
Configurable DIOs: 8 channels
Isolation: 3k VDC or 2k Vrms
Analog Input
Type: Differential Input
Resolution: 16 bits
I/O Mode: Voltage / Current
Input Range: 0 to 10 VDC, -10 to 10 VDC, 0 to 20 mA, 4 to 20 mA
(wire off)
Historical Data Buffering: 60KB per channel, 120 second data buffer
at 250 Hz
Accuracy:
±0.1% FSR @ 25°C
±0.3% FSR @ -40 and 75°C
Sampling Rate:
• All channels: 2000 samples/sec
• Per channel: 250 samples/sec
Input Impedance: 2M ohms (min.)
Built-in Resistor for Current Input: 120 ohms (min.)
Digital Input
Sensor Type: Wet Contact (NPN or PNP), Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact:
NPN (DI to GND):
• On: 0 to 3 VDC
• Off: 10 to 30 VDC
PNP (DI to GND):
• Off: 0 to 3 VDC
• On: 10 to 30 VDC
Common Type: 4 points per COM
Counter Frequency: 1 kHz
Digital Filtering Time Interval: Software selectable (by 0.5 ms)
Digital Output
Type: Sink
I/O Mode: DO or Pulse Output
Pulse Output Frequency: 1 kHz
Over-voltage Protection: 45 VDC
Over-current Protection: 2.6 A (4 channels @ 650 mA)
Over-temperature Shutdown: 175°C (typical), 150°C (min.)
Current Rating: 200 mA per channel
Software Characteristics
Automation Languages: C/C++, IEC 61131-3
Protocols: Modbus/TCP, Modbus/RTU Master
Power Requirements
Power Input: 24 VDC nominal, 9 to 48 VDC
Physical Characteristics
Housing: Aluminum
Dimensions: 90.05 x 135 x 105.4 mm (3.55 x 5.32 x 4.15 in)
Weight:
• ioPAC 5542-HSPA Series: 1100 g
• ioPAC 5542 Series: 1000 g
Mounting: DIN-Rail mounting (standard), wall mounting (optional)
Connector: Spring-type terminal block
Environmental Limits
Operating Temperature:
• ioPAC 5542 Series: -40 to 75°C (-40 to 176°F)
• ioPAC 5542-HSPA Series: -30 to 75°C (-22 to 176°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and Certifications
Safety: UL 508, NCC
Hazardous Location: UL/cUL Class 1 Division 2
EMI: EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B
Class A
EMS: EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN
61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Rail Traffic: EN 50121-4
Note: Please check Moxa’s website for the most up-to-date certication status.
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
