Moxa OnCell G3150A-LTE-EU-T [3/3] Ordering information

Industrial Cellular Solutions

Ordering Information

Available Models

OnCell G3150A-LTE-US: Industrial LTE cellular modem, B2/B4/B5/B13/B17/B25, 0 to 55°C operating

temperature

OnCell G3150A-LTE-US-T: Industrial LTE cellular modem, B2/B4/B5/B13/B17/B25, -30 to 70°C

operating temperature

OnCell G3150A-LTE-EU: Industrial LTE cellular modem, B1/B3/B7/B8/B20, 0 to 55°C operating

temperature

OnCell G3150A-LTE-EU-T: Industrial LTE cellular modem, B1/B3/B7/B8/B20, -30 to 70°C operating

temperature

Note: Please visit Moxa’s website for a complete list of optional wireless accessories and antennas available for Moxa’s wireless products.

Optional Accessories (can be purchased separately)

Package Checklist

• OnCell G3150A-LTE cellular modem

• 2 x UMTS/LTE cellular antennas

• DIN-rail kit

• Quick installation guide (printed)

• Warranty card

PIN RS-232 RS-422/485-4w RS-485-2w

1 DCD TxD-(A) –

2 RxD TxD+(B) –

3 TxD RxD+(B) Data+(B)

4 DTR RxD-(A) Data-(A)

5 GND GND GND

6 DSR – –

7 RTS – –

8 CTS – –

9 – – –

DB9 male connector

1 2 3 4 5

6 7 8 9

Model Name A-CRF-SMSF-R3-100 ANT-LTEUS-ASM-01 ANT-LTE-ASM-02 ANT-GPS-OSM-05-3M WK-36-02

Description Magnetic Mount Antenna

Base: SMA, 1 m

US LTE Antenna, 1 dBi,

2 pcs

EU LTE Antenna, 2 dBi,

2 pcs

GPS Antenna, SMA,

1 m

OnCeell G3150A-LTE

wall-mounting kit, 2 pcs
