Technische Daten
ANALOGBETRIEB
8 symmetrische Mikrofoneingänge mit:
< 20dB Eingangsdämpfung
< 50dB variabler Gain
< Phantomspeisung (48V) mit Anzeige für Kanal 1 bis 4
< Phantomspeisung (48V) mit Anzeige für Kanal 5 bis 8
< Systemverstärkung (symmetrischer Eingang / symmetrischer Ausgang):
19dB bis 70dB
-1dB bis 50dB (bei aktivierter 20dB-Dämpfung)
< Frequenzgang: 20Hz-20kHz, +/- 0,11 dB; mittlerer Gain
< Rauschabstand: 120dB, A-weighted; mittlerer Gain
< Dynamikbereich: 120dB, A-weighted; mittlerer Gain
< THD+N: 0,00041% @ -107dB, 1dB unter der Clipping-Grenze, 22Hz-22kHz; mittlerer Gain
< Geräuschpegelbewertung (EIA): -129dBu @ max. Gain, 600 Ohm, 22Hz-22kHz
< Eingangsimpedanz: 2850 Ohm (ohne Pad-Dämpfung); 3600 Ohm (aktivierte Pad-Dämpfung)
2 unsymmetrische Instrumenteneingänge mit:
< Eingangsimpedanz: mind. 3 MOhm
< Variabler Gain: 44dB
< Die Instrumenteneingänge sind verfügbar, sobald die entsprechenden Anschlüsse belegt sind.
< Systemverstärkung:
6dB bis 50dB (symmetrischer Ausgang)
0dB bis 44dB (unsymmetrischer Ausgang)
< Frequenzgang: 20Hz-20kHz, +/- 0,03 dB; mittlerer Gain
< Rauschabstand: 133dB, A-weighted; mittlerer Gain
< Dynamikbereich: 133dB, A-weighted; mittlerer Gain
< THD+N: 0,0018% @ -95dB, 1dB unter der Clipping-Grenze, 22Hz-22kHz; mittlerer Gain
MS-Matrix (aktiviert; Einstellung auf M):
< Kanäle 7 & 8: Eingänge für M & S
< Kanäle 7 & 8: Ausgänge für L & R
< Matrix: L=M+S/3 und R=M–S/3
Zusätzliche Daten Analogbetrieb:
< Maximale Bewertung des analogen Ausgangssignals (digitales Clipping):
Symmetrisch: +26dBu
Unsymmetrisch: +20dBu
< Eingangsimpedanz (Line-Eingang): 20 kOhm (symmetrisch), 13,3 kOhm (unsymmetrisch)
< Ausgangsimpedanz: 600 Ohm (symmetrisch)
< Kanal 1 Low-Cut-Schalter: -12dB/Oktave bei Frequenzen unter 80Hz
< Phaseninvertierung für Kanal 2, 4, 6 und 8
DIGITALBETRIEB
8 symmetrische/unsymmetische analoge A/D-Eingänge:
< Ausgang: Lightpipe; 8 Kanäle, 24bit, optischer ADAT-Anschluss
< Frequenzgang: 20Hz-20KHz (+/- 1dB)
< Rauschabstand: 110dB, A-weighted
< Dynamikbereich: 110dB, A-weighted
< THD+N: 0,00067% @ -103dB, -1dBFS, 22Hz-22kHz
< Digitales Clipping am Direkteingang: +20dBu
< Signalspitzenanzeige für 3dB, 10dB und 20dB unter der Clipping-Grenze
< Samplefrequenzen (manuelle Auswahl): 44,1kHz; 48kHz und externe Frequenzen (Wordclock)
< Wordclock-Ein- und Ausgang mit Lock-LED, Frequenzbereich: 33kHz bis 59kHz
STROMVERSORGUNG
18 V Wechselstrom (16,5 V Wechselstrom mindestens) @ 3,5A Inline-Netzteil
