IW Accessories

ANT-WCDMA-ANF-00

Five-band GSM/GPRS/EDGE/UMTS/HSPA, 0 dBi, omni-directional,

outdoor antenna

Speciﬁcations

Ordering Information

Antenna Characteristics

Frequency: 850/900/1800/1900/2100 MHz

Anntenna Type: Omni-directional

Typical Antenna Gain: 0 dBi

Connector: N-type (female)

Impedance: 50 ohms

Polarization: Linear, vertical

HPBW/horizontal: 360°

V.S.W.R.: 1.5

Physical Characteristics

Weight: 430 g

Dimensions: Length=420 mm

IP Rating: IP65

Radome Color: White

Radome Material: Fiber Glass

Installation: Pole mount

Environmental Limits

Operating Temperature: -40 to 80°F (-40 to 176°F)

Storage Temperature: -40 to 80°C (-40 to 176°F)

Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)

Warranty

Warranty Period: 1 year

Details: See www.moxa.com/warranty

Package Checklist

• ANT-WCDMA-ANF-00 antenna

• Pole mount kit

Ø35

N-TYPE FEMALE

420

Dimensions

Unit: mm (inch)

Available Models

ANT-WCDMA-ANF-00: Five-band GSM/GPRS/UMTS/HSDPA, omni-directional, 0 dBi, glass ﬁber,

N-type (female)

Can be used with the following products

OnCell G2111/G2151I, OnCell G3111/G3151, OnCell G3211/G3251, OnCell G3100 Series, OnCell G3100-HSDPA Series, OnCell G3100-HSPA

Series, OnCell 5000 Series, OnCell 5000-HSDPA Series, OnCell 5000-HSPA Series

› Waterproof N-type connector

› Lightweight for portable deployment

› Compact form factor

› Pole-mounting support

› Housing provides IP65 protection
