- 12 -
Top View
Camera with SCO1 adaptor
Specifications
Camera
Sensor
1/2.7” HD progressive scan CMOS
Lens
3.6, 4.2, 6 mm fixed focal length
Angle of view
3.6 mm, F1.6: Diagonal 160°, Horizontal 100°,
Vertical 71°
4.2 mm, F1.8: Diagonal 97°, Horizontal 80°,
Vertical 58°
6.0 mm, F1.8: Diagonal 83°, Horizontal 65°,
Vertical 51°
Camera lens angle
Pan: ±30°; Tilt: 0-90°, Rotate: ±180°
(contolled manually)
Illumination
(Low light sensitivity)
0.2 Lux at F=1.2, color
Synchronization
Internal
White Balance
ATW/AWB (range: 3200 to 10000°K)
Electronic Shutter
Auto, 1/30 to 1/25000 sec.
S/N Ratio
50 dB (Gamma, Aperture, AGC, OFF; DNR ON)
DNR
Built-in DNR
WDR
Level 1 to 8
AGC Control
2X, 4X, 8X, 16X, 32X, 64X
Flickerless Control
50Hz/60Hz mode
Black level control
High/Medium/Low
Auto Exposure
Level ±5
Image Rotation
Flip, Mirror, and 180° rotation
Image Setting
Manual tuning with saturation, sharpness, and
contrast
Video
Video Compression
H.264 (ISO/IEC 14496-10) or MJPEG
Video Output
Via Ethernet port
Video Streams
Maximum of 3 video streams (2 H.264 and 1
MJPEG)
• Stream 1: H.264, 1280 x 800 resolution
(max.)
• Stream 2: H.264, 720 x 480 resolution
(max.)
• Stream 3: MJPEG, 720 x 480 resolution
(max.)
Note: Streams 2 and 3 must be set to the same
resolution
