- 3 -
Quick Installation Guide
Documentation and Software CD (includes User’s Manual, Quick
Installation Guide, and VPort Utility)
Warranty card
NOTE
Check the model name on the VPort’s side label to determine if
the model name is correct for your order.
NOTE
This product must be installed in compliance with your local laws
and regulations.
Features
• 1/2.7”HD progressive CMOS image sensor
• High image quality with WDR (wide dynamic range) and DNR (Digital
Noise Reduction) supported
• Minimum illumination is up to 0.2 lux (color)
• Supports MJPEG and H.264 Duall Codecs
• Provides 3 video streams for H.264 and MJPEG simultaneously
• Video stream up to 30 frames/sec at WXGA (1280x800) resolution
• Supports video quality configuration with fixed bit rate (CBR) and
fixed quality (VBR)
• Video latency under 200 ms
• DynaStream™ for network efficiency with dynamic frame rate change
• WXGA/720P/SVGA/ Full D1/ 4CIF/ VGA/ CIF/ QCIF resolution
• TCP, UDP, and HTTP network transmission modes
• Supports DHCP OPT66/67 for automatic configuration from TFTP
server, making it easy to batch configurate several units
• Supports RTSP streaming
• Support multicast (IGMP) video streaming
• Supports SNMP (V1/V2C/V3) for network system integration and
management
• Supports QoS (ToS) for transmission priority
• Built-in web server for easy configuration
• Accessible IP filtering
• UPnP supported
• Compliant with EN 50121-3-2 and relevant sections of EN 50155
(compliant with IEC 60571)
• 1 10/100BaseT(X) port with M12 A-code connector
• 1 audio input with water-proof RCA-type connector
• IP66 rain and dust protection, with dehumidifying membrane
• PoE (Power-over-Ethernet, IEEE 802.3af) supported
• EN 62262 IK8 level vandal resistance
• -25 to 55°C (EN 50155, class T1), or -40 to 75°C (EN 50155. Class TX)
operating temperature for rolling stock environments
• CE, FCC, UL 60950-1
• Built-in tamper alarm and Video Motion Detection (VMD)
• Pre, Trigger, and post snapshot images supported
• Sequential snapshot images supported
• Supports SMTP and FTP for alarm message transmission
• Supports HTTP event server
• 5-year warranty
