- 5 -

• RCA female connector: The VPort P06-1MP-M12 supports one

audio input with RCA female connector. The audio will be digitized

and compressed as an audio stream for network transmission with

the video stream.

NOTE

RCA audio connectors are popular and easily found in the market.

If you require any other kind of audio connector, please contact

your Moxa sales representative for customization service.

• Solid plastic top cover: This top cover can be removed for tuning

the camera lens position.

• Transparent dome cover: The VPort P06-1MP-M12 is designed

with a transparent PC dome cover, which is vandal-proof with EN

62262 (IEC 62262) class IK8 level.

• 2 Torx screws for top cover: These 2 torx screws are designed

with anti-shedding to make installation more convenient. Use the

L-type torx screwdriver to remove or attach the top cover.

NOTE

The color of the form factor can be customized based on your

installation environment. Please

contact your Moxa sales

representative for customization service.

Inside the Camera

• Mounting screw holes: There are 4 mounting screw holes for

mounting the VPort P06-1MP-M12 on the ceiling or the accessory.

• Thumb screw for fixing the lens’s position: To tune the lens’s

position, loosen the thumb screw, and then retighten it after the

position tuning is done.

• Lens with fixed focal length: The VPort P06-1MP-M12 series

includes models with 3 different focal lengths. Choose the appropriate

focal-length lens based on the viewing angle and object distance.

• Hardware reset button: Use a pointed object to depress the reset

button to reboot or restore factor defaults.

 Reboot: press the button one time.

 Factory default: press the button and hold in for at least 5 sec.
