VPort P06-1MP-M12 Introduction

1-2

Overview

The compact VPort P06-1MP-M12 cameras provide a HD (720P, 1280 x 720) video image, and feature an

H.264/MJPEG IP dome, giving them the versatility and ruggedness to excel in many different installations and

environments for mobile IP video surveillance applications. In addition, the cameras feature EN 50155

compliance, vandal-proofing (EN 62262 IK8), -25 to 55°C or -40 to 70°C (T models) operating temperature, a

rugged M12 Ethernet port, 1 audio input, PoE power inputs, IP66 rain and dust protection, a dehumidifying

membrane, and a selectable lens.

Excellent Image Quality

The VPort P06-1MP-M12 is equipped with a cutting-edge CMOS sensor, which provides excellent high

resolution video images at 1280 x 800 pixels and covers larger areas than legacy analog cameras. With the

addition of DNR (Digital Noise Reduction), BLC (Black Level Control), and WDR (Wide Dynamic Range)

functions, the VPort P06-1MP-M12 provides an extremely clear picture of the surveillance region.

Rugged Hardware Design

The VPort P06-1MP-M12’s 47 mm height makes it ideal for tough vehicle environments with limited installation

space. It is compliant with EN 50121-3-2 (EMC), EN 61373 for shock and vibration, and essential sections of EN

5015, with standard models designed for T1 temperatures, and wide temp. models designed to withstand TX

temperatures (-40 to 70°C; note that the T models are also tested for 10 min. at +15°C over the max. of 75°C),

without a fan or other cooling equipment. Moreover, the VPort P06-1MP-M12 achieves the highest enclosure

protection, IEC 62262 Class IK8, providing users with a true, vandal-proof IP camera.

High Video Performance

The VPort P06-1MP-M12 is designed to provide both H.264 and MJPEG video streams and transmit a maximum

of 3 independent video streams (2 H.264, 1 MJPEG) simultaneously. In addition, Moxa’s DynaStream™

function allows you to change the video frame rate automatically, which can help you control your network

bandwidth budget and ease network system management. A DHCP Opt66/67 auto-configuration mechanism

simplifies the workload of mass installation and maintenance by backing up the configuration on a TFTP server.

Package Checklist

Moxa’s VPort P06-1MP-M12 Series is shipped with the following items. If any of these items is missing or

damaged, please contact your customer service representative for assistance.

• 1 × VPort P06-1MP-M12 series (lens included)

Standard Temp. Models Wide Temp. Models Lens

VPort P06-1MP-M12-CAM36 VPort P06-1MP-M12-CAM36-T 3.6 mm

VPort P06-1MP-M12-CAM42 VPort P06-1MP-M12-CAM42-T 4.2 mm

VPort P06-1MP-M12-CAM60 VPort P06-1MP-M12-CAM60-T 6.0 mm

• Screw handle accessory package

Torx screw driver for

attaching/detaching the upper

case

4 sets of nuts, gaskets and spring

washers for mounting the camera

4 indented hexagon head tapping

screws for mounting the camera on

the ceiling
