VPort P06-1MP-M12 Introduction

1-3

• Sticker for camera mounting positions

• Quick installation guide

• Documentation and software CD (includes User’s Manual, Quick Installation Guide, and VPort Utility)

• Warranty card

NOTE: Notify your sales representative if any of the above items is missing or damaged.

NOTE

Check the model name on the VPort’s side label to determine if the model name is correct for your order.

NOTE

This product must be installed in

compliance with your local laws and regulations.

Product Features

• 1/2.7”HD progressive CMOS image sensor

• High image quality with WDR (wide dynamic range) and DNR (Digital Noise Reduce) supported

• Minimum illumination is up to 0.2 lux (color)

• Supports MJPEG and H.264 Dual Codecs

• Provides 3 video streams for H.264 and MJPEG simultaneously

• Video streams at up to 30 frames/sec at WXGA (1280x800) resolution

• Supports video quality configuration with fixed bit rate (CBR) and fixed quality (VBR)

• Video latency under 200 ms

• DynaStream™ supported for network efficiency with dynamic frame rate change

• CBR Pro™ supported for high image quality in limited bandwidth transmissions

• WXGA/720P/SVGA/ Full D1/ 4CIF/ VGA/ CIF/ QCIF resolution

• TCP, UDP, and HTTP network transmission modes

• Supports DHCP OPT66/67 for automatic configuration from TFTP server, making mass installation easier

• Supports RTSP Streaming

• Supports Multicast (IGMP) video streaming

• Supports SNMP (V1/V2C/V3) for network system integration and management

• Supports QoS (ToS) for transmission priority

• Built-in web server for easy configuration

• Accessible IP filtering

• UPnP supported

• Compliant with EN 50121-3-2 and relevant sections of EN 50155 (compliant with IEC 60571)

• 1 10/100BaseT (X) with M12 D-code connector
