Wiring Requirements

ATTENTION

Safety First!

Be sure to disconnect the power cord before installing and/or

wiring your Moxa VPort

P06HC-1MP-M12. Calculate the

maximum possible current in each power wire and common wire.

Observe all electrical codes dictating the maximum current

allowable for each wire size. If the current goes above the

maximum ratings, the wiring could overheat, ca

using serious

damage to your equipment.

You should also pay attention to the following:

• Use separate paths to route wiring for power and devices. If power

wiring and device wiring paths must cross, make sure the wires are

perpendicular at the intersection point.

• You can use the type of signal transmitted through a wire to

determine which wires should be kept separate. The rule of thumb is

that wiring that shares similar electrical characteristics can be

bundled together.

• Keep input wiring and output wiring separated.

• We strongly advise labeling wiring to all devices in the system.

Dimensions (mm)

Front View

Bottom View
